Dây Cáp Điện LAPP KABEL ÖLFLEX® CLASSIC 128 H BK SC, -40°C to +80°C | Chính Hãng – Giá Tốt Nhất
Hãng sản xuất: LAPP KABEL
Xuất xứ thương hiệu: Germany
(Giấy tờ: CO,CQ,BIL,PACKING LIST, TỜ KHAI đầy đủ)
LAPP KABEL ÖLFLEX® CLASSIC 128 H BK SC là dòng cáp điện không halogen, chống cháy và ít khói, sử dụng ruột đồng trần nhiều sợi mảnh, cách điện Halogen-free và vỏ ngoài bằng hợp chất đặc biệt không halogen màu đen. Thiết kế mềm dẻo giúp dễ dàng thi công, lắp đặt, đồng thời vật liệu không halogen và khả năng chống cháy cao giúp hạn chế lan truyền lửa, khói và khí độc khi xảy ra sự cố.
Cáp phù hợp cho tòa nhà công cộng, hệ thống giao thông, nhà máy, máy móc công nghiệp, hệ thống HVAC và các ứng dụng ngoài trời, đặc biệt tại những khu vực có yêu cầu cao về an toàn cho con người, động vật và tài sản. Sản phẩm chịu UV, thời tiết và ozone, đáp ứng IEC 60332, IEC 60754, IEC 61034, ISO 4892-2, EN 50396 và dựa trên EN 50525-3-11.
ÖLFLEX® CLASSIC 128 H BK SC
Cost-effective halogen-free single core power cable with improved fire characteristics, 0,6/1kV
ÖLFLEX® CLASSIC 128 H BK SC, Single core power cable, halogen-free, highly flame retardant, HFFR, flexible, conductor class 5, public buildings
- For space-saving and cost-effective installation
- For use within public buildings and industrial plants
- CPR: Article number choice under www.lappkabel.com/cpr
Benefits
- Easy handling and installation due to flexible design
- Intended for use under the European Construction Product Regulation (CPR), refer to catalogue appendix T14
- Halogen-free and highly flame-retardant materials reduce the risk of fire propagation, high smoke density and toxic fumes in case of fire
- Variants ‘RD’ and ‘WH’ with red respectively white insulation colour for DC systems according to DIN EN 60445.
Application range
- For use within public buildings and industrial plants
- Plant engineering
Industrial machinery
Heating and air-conditioning systems - Particularly where human and animal life as well as valuable property are exposed to high risk of fire hazards
- Suitable for outdoor applications
- For use within public buildings, transport systems and industrial plants
Product features
- Flame-retardant according to IEC 60332-1-2
(flame spread on a single cable) - No flame-propagation according to IEC 60332-3-24 respectively IEC 60332-3-25 (Flame spread on vertical cable or wire bundle)
- Halogen-free according to IEC 60754-1
(amount of halogen acid gas)
Corrosiveness of combustion gases according to IEC 60754-2 (degree of acidity) - Low smoke density according to IEC 61034-2
- UV and weather-resistant according to ISO 4892-2
- Ozone-resistant according to EN 50396
Norm references / Approvals
- Based on EN 50525-3-11
Product Make-up
- Fine-wire strand made of bare copper wires
- Core insulation: Halogen-free
- Outer sheath made of special halogen-free coumpound, black
Technical Data
Classification ETIM 5
- ETIM 5.0 Class-ID: EC000057
- ETIM 5.0 Class-Description: Low voltage power cable
Classification ETIM 6
- ETIM 6.0 Class-ID: EC000057
- ETIM 6.0 Class-Description: Low voltage power cable
Core identification code
- Black or green-yellow, other colours available on request
Conductor stranding
- Fine wire according to VDE 0295 Class 5/ IEC 60228 Class 5
Torsion movement in WTG
- TW-0 & TW-1, refer to Appendix T0
Minimum bending radius
- Occasional flexing: 15 x outer diameter
- Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 600/1000 V
- DC (core-ground): max. 0,75 kV
DC (core-core): max. 1,5 kV
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Occasional flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
| Article number | Number of cores and mm² per conductor | Outer diameter [mm] | Colour | Copper index (kg/km) | Weight (kg/km) | |
|---|---|---|---|---|---|---|
|
1123800
|
1 X 16.0 | 9.6 | black | 153.6 | 219 | |
|
1123811
|
1 G 16.0 | 9.6 | green-yellow | 153.6 | 219 | |
|
1123821
|
1 X 16 | 9.6 | white | 153.6 | 219 | |
|
1123831
|
1 X 16 | 9.6 | red | 153.6 | 219 | |
|
1123801
|
1 X 25 | 11.3 | black | 240 | 327 | |
|
1123812
|
1 G 25 | 11.3 | green-yellow | 240 | 327 | |
|
1123822
|
1 X 25 | 11.3 | white | 240 | 327 | |
|
1123832
|
1 X 25 | 11.3 | red | 240 | 327 | |
|
1123802
|
1 X 35 | 12.5 | black | 336 | 436 | |
|
1123813
|
1 G 35 | 12.5 | green-yellow | 336 | 436 | |
|
1123823
|
1 X 35 | 12.5 | white | 336 | 436 | |
|
1123833
|
1 X 35 | 12.5 | red | 336 | 436 | |
|
1123803
|
1 X 50 | 15.1 | black | 480 | 587 | |
|
1123814
|
1 G 50 | 15.1 | green-yellow | 480 | 587 | |
|
1123824
|
1 X 50 | 15.1 | white | 480 | 587 | |
|
1123834
|
1 X 50 | 15.1 | red | 480 | 587 | |
|
1123804
|
1 X 70 | 17.0 | black | 672 | 798 | |
|
1123815
|
1 G 70 | 17.0 | green-yellow | 672 | 798 | |
|
1123825
|
1 X 70 | 17 | white | 672 | 798 | |
|
1123835
|
1 X 70 | 17 | red | 672 | 798 | |
|
1123805
|
1 X 95 | 19.6 | black | 912 | 1044 | |
|
1123816
|
1 G 95 | 19.6 | green-yellow | 912 | 1044 | |
|
1123826
|
1 X 95 | 19.6 | white | 912 | 1044 | |
|
1123836
|
1 X 95 | 19.6 | red | 912 | 1044 | |
|
1123806
|
1 X 120 | 22.4 | black | 1152 | 1339 | |
|
1123817
|
1 G 120 | 22.4 | green-yellow | 1152 | 1339 | |
|
1123827
|
1 X 120 | 22.4 | white | 1152 | 1339 | |
|
1123837
|
1 X 120 | 22.4 | red | 1152 | 1339 | |
|
1123807
|
1 X 150 | 24.2 | black | 1440 | 1633 | |
|
1123818
|
1 G 150 | 24.2 | green-yellow | 1440 | 1633 | |
|
1123828
|
1 X 150 | 24.2 | white | 1440 | 1633 | |
|
1123838
|
1 X 150 | 24.2 | red | 1440 | 1633 | |
|
1123808
|
1 X 185 | 26.3 | black | 1776 | 1943 | |
|
1123819
|
1 G 185 | 26.3 | green-yellow | 1776 | 1943 | |
|
1123829
|
1 X 185 | 26.3 | white | 1776 | 1943 | |
|
1123839
|
1 X 185 | 26.3 | red | 1776 | 1943 | |
|
1123809
|
1 X 240 | 30.8 | black | 2304 | 2597 | |
|
1123820
|
1 G 240 | 30.8 | green-yellow | 2304 | 2597 | |
|
1123830
|
1 X 240 | 30.8 | white | 2304 | 2597 | |
|
1123840
|
1 X 240 | 30.8 | red | 2304 | 2597 |
