CAT 6A Shielded (Alloy) In-Line Keystone Coupler 568A/B

Description
Alantek Cat6 and 6A Shielded (Alloy) In-Line Keystone Coupler are designed to provide superior performance, reliabilityand fast connection. It advanced circuit design and alloy body provide optimum signal quality, allowing it to exceed TIA/EIA and ISO Category 6 and 6A respectively performance standards.The slim design offers a smaller footprint maximizing space in confined area.
Application
Suitable for used in 10Base-T to Gigibit/10 Gigabit Ethernet application. Enable quick connection/installation for
Consolidation Point or Pre-Termination solution. Support all type of Alantek faceplate and Modular Patch Panel.
Standard
• ANSI/TIA 568C.2 Category 6 / 6A
• ISO 11801 Class D / E Standard
• TIA/EIA TSB-40
• CENELEC EN50173
• UL 1863
• UL94V-0
Features
• Slim, Modular and Low Profile design allow high density application
• Support both T568A and T568B wiring
• Support 10Base-T to Gigibit/10 Gigabit Ethernet application
Characteristics
• Insulation Resistance: 500 m-Ω @ 100V DC
• Dielectric Withstand Voltage: 1000 V AC/DC
• Peak to Peak : 60 Hz 1 min
• Housing: PC UL94V-0 (High Impact, Fire retardant plastic) enclosed by Zinc-Alloy housing
• Contact: Phosphor Bronze Alloy plated with 50 microngold
• 750 Cycles (min) Insertion and Extraction life
• Spring Wire : Phosphor Bronze Alloy plated with 50 micron Gold

Part No. Description
302-2026F1-CPAB Cat 6 Shielded In-Line Keystone Coupler
