Cáp mạng Belden Cat5e UTP 4 Pair 24 AWG | PN: YJ55169 008U1000 chính hãng
Giới thiệu sản phẩm cáp mạng Belden Cat5e UTP 4 Pair 24 AWG
Cáp mạng Belden Cat5e UTP là dòng sản phẩm thông dụng được sử dụng nhiều tại các hệ thống mạng tại Việt Nam. Với tiêu chuẩn của cáp mạng Cat5e nói chung, Dây mạng Belden UTP 4 Pair 24 AWG cũng sử dụng 4 cặp dây đồng nguyên chất được xoắn với nhau thành từng cặp giúp đường truyền đạt tốc độ cao nhất và giảm tối đa xung nhiễu chéo nhau giữa các cặp dây dẫn.
Cáp mạng Cat5e Belden YJ55169 008U1000 sử dụng phần vỏ làm từ nhựa PVC cao cấp thân thiện với môi trường và không gây độc hại cho con người trong quá trình sử dụng.
Dây cáp mạng Belden Cat5e UTP được đóng hộp với chiều dài chuẩn 1000ft tương đương 305m. Dây có màu xám
Sản phẩm cáp mạng Belden đáp ứng đầy đủ các tiêu chuẩn như :
RoHS: Tương thích TIA/EIA 568C.2 Cat5e
ISO/IEC 11801 phân hạng D
Description:
24 AWG solid bare copper conductors, non-plenum, Polyolefin insulation, twisted pairs, see color code chart (below), rip cord, PVC
jacket (blue or grey).
SUITABLE APPLICATIONS:
Suitable Applications Premise Horizontal Cable, Gigabit Ethernet, 100BaseTX, 100BaseVG
ANYLAN, 155ATM, 622ATM, NTSC/PAL Component or Composite Video,
AES/EBU, Digital Video, RS-422
CONDUCTOR: |
|
| Number of Pairs | 4 |
| Total Number of Conductors | 8 |
| AWG | 24 |
| Stranding | Solid |
| Conductor Material | BC – Bare Copper |
INSULATION: |
||
| Insulation Material | PO – Polyolefin | |
| Pair Color Code Chart: | ||
Pair Number |
Insulation Color | |
| 1 | Blue | White with Blue Stripe |
| 2 | Orange | White with Orange Stripe |
| 3 | Green | White with Green Stripe |
| 4 | Brown | White with Brown Stripe |
OUTER SHIELD: |
||
| Outer Shield Material | Unshielded | |
OUTER JACKET: |
||
| Outer Jacket Material | PVC – Polyvinyl Chloride | |
| Outer Jacket Ripcord | Yes |
| Overall Nominal Diameter | 5.0 mm |
MECHNICAL CHARACTERISTICS : |
|
| Operating Temperature Range | – 15℃ To + 60℃ |
| Bulk Cable Weight | 29 kg/km |
| Max. Recommended Pulling Tension | 78 N |
| Min. Bend Radius (Install) | 40 mm |
ELECTRICAL CHARACTERISTICS: |
|
| Nom. Mutual Capacitance @ 1 KHz | 5.6 nF/100m |
| Maximum Capacitance Unbalance | 330 pF/100m |
| Minimum Velocity of Propagation @ 100MHz | 62 % |
| Maximum Delay @ 100 MHz | 538 ns/100m |
| Maximum Delay Skew | 45 ns/100m |
| Maximum Conductor DC Resistance @ 20 Deg.C | 9.38 Ohms/100m |
| Maximum DCR Unbalance @ 20 Deg.C | 5 % |
| Maximum Intended Operating Voltage | 80 V RMS |
ELECTRICAL CHARACTERISTICS – PREMISES: |
||||||
| Premise Cable Electricals Table 1: | ||||||
| Frequency (MHz) | Max. Attenuation (dB/100m) |
Min. NEXT (dB) |
Min. PSNEXT (dB) |
Min. Return Loss (dB) |
Min. ELFEXT (dB) |
Min. PSELFEXT (dB) |
| 1 | 2.0 | 65.3 | 62.3 | 20.0 | 63.8 | 60.8 |
| 4 | 4.1 | 56.3 | 53.3 | 23.0 | 51.7 | 48.7 |
| 8 | 5.8 | 51.8 | 48.8 | 24.5 | 45.7 | 42.7 |
|
NOTES: |
|
| Notes | Jacket sequentially marked. |
