7834A – Belden Category 6+ UTP Cable
DESCRIPTON: 23 AWG solid bare copper conductors, non-plenum, Polyolefin insulation, twisted pairs, central spline, rip cord, see color code chart (below), PVC jacket (blue or grey).
SUITABLE APPLICATIONS: Premise Horizontal Cable, Gigabit Ethernet, 100BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM, NTSC/PAL Component or Composite Video, AES/EBU, Digital Video, RS-422, 250MHz Category 6.
PHYSICAL CHARACTERISTICS:
| Number of Pairs | 4 |
| Total Number of Conductors | 8 |
| AWG | 23 |
| Stranding | Solid |
| Conductor Material | BC – Bare Coppe |
OUTER JACKET:
Outer Jacket Material: PVC – Polyvinyl Chloride
OUTER SHIELD:
Outer Shield Material: Unshielded
MECHNICAL CHARACTERISTICS:
| Operating Temperature Range | – 20℃ To + 75℃ |
| Bulk Cable Weight | 65 kg/km |
| Max. Recommended Pulling Tension | 180 N |
| Min. Bend Radius (Install) | 13.0 mm |
