    • Tên sản phẩm: Cáp mạng Belden Cat6 F/UTP
    • Mã sản phẩm:  Belden 10GXE00
    • Hãng sản xuất:  Belden
    • Xuất xứ: China
    • Belden Cat6 F/UTP Twisted pair Gigabit Ethernet Cable 23AWG, 4-pair

Product Description
Category 6A (625MHz), 4-Pair, F/UTP-Foil shielded, Premise Horizontal Cable, 23 AWG Solid Bare Copper Conductors, Polyethylene Insulation, Beldfoil®
shield, AWG 26 solid tinned copper drainwire, LSZH Jacket, CPR Euroclass Eca

Suitable Applications: Horizontal and building backbone cable; Support current and future Category 6A and 6 applications, such as: 10GBase-T (10 Gigabit Ethernet), 1000Base-T
(Gigabit Ethernet), 100 Base-T, 10 Base-T, FDDI, ATM

Conductor :

Element AWG Stranding Material No. of Pairs
Individual pair 23 Solid BC – Bare Copper 4
Conductor Count: 8
Total Number of Pairs: 4

Insulation :

Element Type Material Nominal Diameter
Individual pair c PE – Polyethylene Solid 1.18 mm

Color Chart  :

Number Color
Pair 1 White/Blue & Blue
Pair 2 White/Orange & Orange
Pair 3 White/Green & Green
Pair 4 White/Brown & Brown

Cabling :

Description
4 pairs twisted together + cross web of polyolefin

Outer Shield :

Type Material Coverage [%] Drainwire Material Drainwire AWG Drainwire Construction n x D Drainwire Position
Tape Bi-Laminate (Alum+Poly) 100% TC – Tinned Copper 26 Solid outside aluminum foil
Table Notes: Aluminum facing outside

Outer Jacket :

Material Nominal Diameter Diameter +/- Tolerance Ripcord
LSZH – Low Smoke Zero Halogen (Flame Retardant) 7.2 mm 0.3 mm Yes

Construction and Dimensions :

Min Elongation at Breakof Conductors: 10%
Min Elongation at Breakof Insulation: 100%
Min Elongation at Breakof Jacket: 100%
Min Tensile Strength of Jacket: 9 Mpa

Conductor DCR :

Max. Conductor DCR Max DCR Unbalanced Between Pairs [%] Max. DCR Unbalanced Within Pair [%]
95 Ohm/km 4% 2%

Capacitance :

Max. Capacitance Unbalance   :    160 pF/100m

Max. Mutual Capacitance         :      56 pF/m

Impedance :

Nominal Characteristic Impedance :  100 Ohm

Delay :

Max. Delay Skew                                       : 45 ns/100m

Nominal Velocity of Propagation (VP) [%] : 67%

DATASHEET
