Cáp Chống cháy BELDEN ( ZC6ACFU02 ) 1 x 2 x 16AWG MGT/XLP/LSZH Fire resistance | Chính Hãng – Chống Cháy – Giá Tốt Nhất
Thương hiệu/ Brand-name: Belden
Mã hàng/ Part number: ZC6ACFU02
Tiết diện lõi dẫn/ Conductor size: 1x2x16 AWG
Số cặp/ No. of pair: 1 cặp # 2 lõi/ 1 pair # 2 cores/ 1 đôi # 2 sợi
Quy cách/ Length: 305m/cuộn – 305m/drum
Điện áp/ Voltage: 300V
Vỏ ngoài/ Outer jacket, Colour: LSZH, màu Đỏ/ LSZH, RED colour.
Belden Industrial 3 Hours Fire Resistant Circuit Integrity (CI) Cable
Belden’s Multi-Conductor Fire Resistant Cables ensure continued operation in industrial environments, to be employed in controlled shutdown or
emergency situations in circuitry that pertains to mission-critical industrial processes. These cables are also used for fire alarm and PAVA system
installation in verticals like airports, theme parks, high rise buildings, hotels, mass transit systems, railway stations etc. Belden Fire Resistant cables have
gone through rigorous fire tests like BS6387 CWZ (950°C for 180 minutes), IEC 60331-23 (750°C for 90 minutes), EN 50200 (842°C for 120 minutes).
Part No :
ZC6ACFU02
Conductor Size :
16 AWG
Armor :
Unarmored
No. of Pairs :
2
Standard Unit Weight (kg) :
84.9
Nominal Jacket Thickness (mm) :
0.9
Nominal Diameter (mm) :
8.8
Nominal DC Resistance ( /km) :
13.5
Fire Survival And CircuitIntegrity Cables
Belden’s new range of fire survival cable for continous operation of emergency circuits, zero emission of harmful smoke and fire containment in critical and hazardous applications
