Cáp LAPP KABEL UNITRONIC® ST 2095 PE

Data communication systems
Low frequency data transmission cables
Metal foil screened pairs

LAPPKABEL UNITRONIC® ST 2095 PE

• product information ( PDF )

■ Application range

• Suitable connection for audio, control signal and instrument measurement

• For use in dry and damp environment

■ Product features

• 100% screen coverage, offers optimum protection against external interference at medium and high frequencies

• Flame retardant in acc. to IEC 60332-1-2

■ Approvals (Norm references)

■ Design

• Multi-wire strands of bare copper wires

• PE core insulation

• Overall screening with aluminium foil

• Tinned annealed copper drain wire

• PVC outer sheath

• Colour: pebble grey, RAL 7032

Technical data

Core identification code
black, red, natural
Mutual capacitance
C/C: approx. 90 pF/m (20 AWG)
C/C: approx. 78.5 pF/m (18 AWG)
C/S: approx. 160 pF/m (20 AWG)
C/S: approx. 158 pF/m (18 AWG)
Peak operating voltage
300 V (not for power applications)
Minimum bending radius
10 x cable diameter
Test voltage
1000 V
Temperature range
-30°C to +80°C
