NetKey® Copper Cable
NUC6C04BU-FE Cáp mạng lõi đồng, Cat 6 UTP, CM, 4 đôi, ruột dẫn là 24 AWG, được xoắn theo từng cặp, được phân tách bằng một cặp tích hợp được phân chia và bảo vệ bằng vỏ ngoài PVC, màu xanh lam.
Thông số kỹ thuật
| Note | Available in Asia Pacific and South America |
| Environment | Indoor |
| Performance Level | Category 6 |
| Cable Construction | U/UTP |
| Flammability Rating | CM |
| EuroClass Rating | Eca |
| LP Rating | NA |
| Resistance Properties | Flame-Resistant |
| Jacket Material | Polyvinyl chloride |
| Nominal Cable Outside Diameter (In.) | 0.22 |
| Nominal Cable Outside Diameter (mm) | 5.6 |
| Maximum Operating Temperature (°C) | 60 |
| Maximum Operating Temperature (°F) | 140 |
| Minimum Operating Temperature (°C) | -20 |
| Minimum Operating Temperature (°F) | -4 |
| Maximum Installation Temperature (°C) | 50 |
| Maximum Installation Temperature (°F) | 122 |
| Minimum Installation Temperature (°C) | 0 |
| Minimum Installation Temperature (°F) | 32 |
| Sub Brand | NetKey® |
| Maximum Installation Tension (lb) | 25 |
| Maximum Installation Tension (N) | 110 |
| Bend Radius (In.) | 0.88 |
| Bend Radius (mm) | 22.4 |
| Number of Pairs | 4 |
| Conductor Material | Copper |
| Conductor Type | Solid |
| Overall Length (m) | 305 |
| Conductor Gauge (AWG) | 24 |
| Insulation Material | HDPE |
| Acidity Rating | NA |
| Insulation Diameter (In.) | 0.03 |
| Insulation Diameter (mm) | 0.8 |
| Standards Met | Meets ANSI/TIA-568-C.2 Category 6 and ISO 11801 2nd Edition Class E channel requirements; PoE Compliance: Meets IEEE 802.3af and IEEE 802.3at for PoE applications; CE Complaint: EuroClass Eca; RoHS Compliant |
| Color | Blue |
| Flaming Droplets Rating | NA |
| Overall Length (ft.) | 1 |
| Packaging Type | Easy Payout Carton |
| Product Type | Copper Cable |
| Smoke Rating | NA |
| EuroClass Flame Rating | Eca |
