Thanh Đấu Nối LS-VINA ( LS-PP-SC6-24P ) 24-Port Shielded CAT6 Patch Panel ,UL Listed & RoHS Compliant | Chống Nhiễu
Description
LS Simple™ 90° IDC type Category 6 Shielded Patch Panel
• With accessories & full installation instructions
• Individually terminated using 90° IDC(Insulation Displacement Connectors)
• FCC 47 CFR part 68 (RJ-45), ANSI/TIA-568-C.2(Category 6) and ISO/IEC 11801 compliant
• RoHS complaint
• Mounting on 19inch standard rack (EIA-310-D)
• Mounted wire management
Application
• Horizontal Distribution & Backbone Cabling
• 4/16 Mbps Token Ring (IEEE 802.5)
• 10/100/1000BASE-T (IEEE 802.3)
• 155 Mbps ATM
• 100Mbps TP-PMD
• ISDN, ADSL
• 1.2Gbit LAN
Technical Details
| Item | Unit | Specification |
| FEATURE | ||
| Approvals | UL Listed | |
| Category | ANSI/TIA-568-C.2 Category 6 | |
| Meet | 47 CFR part 68 | |
| Wiring scheme | T568A/T568B | |
| ELECTRICAL | ||
| Current Rating | Amps | 1.5 |
| Insulation Resistance | Mega‐ohm | > 500 |
| Contact Resistance | milli‐ohm | < 20 |
| DC Resistance | ohm | < 0.1 |
| Voltage | VAC | < 150 |
| MECHANICAL | ||
| Insertion Life | Mating cycles | 750 |
| Pull Force | lbs(N) | 20(89) |
| Temperature | ℃ | ‐40 ~ 68 |
| Humidity | % | 10 ~ 90 |
| IDC accept | AWG | 22~26 (Solid wire) |
| PHYSICAL | ||
| Cap & Housing | ABS high-impact UL94V-0 thermoplastic Phosphor bronze plated with 30μin gold over |
Part Numbers
| Description | Dimension (H x W, inch) |
Part Number | Compatible Items |
| 24-port Category 6 Shielded Patch Panel |
1.75 x 19 | LS-PP-SC6-24P | Rack : 19inch standard 1U rack Tool : LS-TOOL-MJ, LS-STOOL |
Drawing
LS-PP-SC6-24P
Bản đấu nối cáp CAT6,24 cổng,chống nhiễu,UL
Listed và RoHS
24-Port Shielded CAT6 Patch Panel ,UL Listed &
RoHS Compliant
DATA SHEET
