Cáp Quang Alantek Indoor Multi-unit Distribution Fiber Optic Cable SM 9/125µm, OM4-OM3-OM2 50/125µm, OM1 62.5/125µm | 36-48-60-72-96-108-144 Cores

Indoor Multi-unit Distribution Fiber Optic Cable

Description
The fiber, either single mode or multimode type, are positioned in a
sub-unit jacket, containing water blocking Aramid yarn and 12 fiber.
This multi-unit design allow sub-unit to be routed to different area/
panel, ease termination and connection. A Fiber Reinforced Plastic (FRP)
locates in the center of the core as a non-metallic strength member.
Sub-unit are stranded around the strength member into a compact and
circular cable core, thus achieving 12-144 fiber. Each fiber is mechanically
reinforced with two successive sheaths of 400µm and 900µm which
enables direct termination of connectors.
Application
This cable is suitable for Indoor Distribution in Riser or Fiber-to-the-Desk.
Standards
TIA/EIA 568-C, ISO 11801, IEEE 802.3, ITU Recommendations
Characteristics
•     Accurate fiber excess length ensures good mechanical and temperature performance
Cable Properties

Physical Characteristics

DATA SHEET
