Cáp Quang Alantek Indoor/Outdoor Non-Metallic Fiber Optic Cable 9/125 µm, OM4-OM3-OM2 50/125 µm, OM1 62.5/125 µm | 4-6-8-12-24-36-48-96-144 Fiber

INDOOR/OUTDOOR NON-METALLIC FIBER OPTIC CABLE

NMS Series

Description
The fiber, either single mode or multimode type, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A Fiber Reinforced Plastic (FRP) locates in the centre of the core as a non-metallic strength member. Tubes (and fillers) are stranded around the strength member into a compact and circular cable core. The cable core is filled with filling compound and completed with overall Polyethylene (PE) or Fire Retardant LSZH sheath.
Application
This cable is suitable for Indoor or Outdoor Direct Burial, Tunnel and Duct environment for metropolitan network and access network, where metallic element is not allowed. The PE Sheath provides UV and Chemical/Oil resistance.
Standards
TIA/EIA 568-C, ISO 11801, IEEE 802.3, ITU Recommendations
Characteristics
•     Accurate fiber excess length ensures good mechanical and temperature performance
•     High strength loose tube that is hydrolysis resistant and filling compound ensure a critical protection of fiber
•     Specially designed compact structure is good at preventing loose tube from shrinking
•     Crush resistance and flexibility
•     Single Fiber Reinforced Plastic used as the central strength member
•     Loose tubes are filled with filling compound to ensures tubes are watertight.
•     100% cable core filling ensures cable is watertight

Cable Properties

Physical Characteristics

DATA SHEET
