Cáp Quang LS-VINA ( LT-DJBGEXX/BRN MG2XXX(06T2.00) ) Outdoor/Indoor, Loose Tube, Multimode, OM2, 50/125um, 2 Cores, Single PE Jacket, Non Armor, Black

Fiber Optic Loose Tube Cable
Single/Double Jacketed Loose Tube Cable

Description
•Single Jacket Loose Tube cable is
a UV-stabilized, fully water blocked cable
for In/Outdoor duct applications.
•Loose tube design provides stable and highly
reliable transmission parameters for a variety of
voice, data, video and imaging applications.
•This lightweight cable offers durability and
flexibility required for many outside plant uses.
•RoHS (Restriction of the use of Certain Hazardous
Substances Directive) complied

Specification
•Telcordia GR-20-CORE
•IEC 60793, 60794
•IEC 60332-1,3
•IEEE 383

Construction
•Fiber – Single mode, multi mode(50um/62.5um) available
•Sequential meter or footage markings
•Outer jacket : Black UV and moisture-resistant
LSZH(Low Smoke Zero Halogen)
or PE(Polyethylene)

Color Identification

01 – Blue	07 – Red
02 – Orange	08 – Black
03 – Green	09 – Yellow
04 – Brown	10 – Violet
05 – Slate	11 – Rose
06 – White	12 – Aqua

Mechanical Characteristics
Storage Temperature : -40 to 70℃/ Operating Temperature : -40 to 70℃

Fiber Count	Nominal Outer Diameter		Nominal Weight		Maximum Tensile Load				Crush Load				Minimum Bend Radius
	Nominal Outer Diameter		Nominal Weight		Short Term		Long Term		Short Term		Long Term		Loaded		Installed
	[mm]	[Inch]	[kg/km]	[lb/kft]	[N]	[lb]	[N]	[lb]	[N/cm]	[lb/Inch]	[N/cm]	[lb/Inch]	[mm]	[Inch]	[mm]	[Inch]
6	10.5	0.41	86	58	2,700	125	1,000	46	110	63	55	31	21	8.27	10.5	4.13
12	10.5	0.41	86	58	2,700	125	1,000	46	110	63	55	31	21	8.27	10.5	4.13
24	10.5	0.41	86	58	2,700	125	1,000	46	110	63	55	31	21	8.27	10.5	4.13
36	10.5	0.41	86	58	2,700	125	1,000	46	110	63	55	31	21	8.27	10.5	4.13
48	11	0.43	92	62	2,700	125	1,000	46	110	63	55	31	22	8.66	11	4.33
72	11	0.43	92	62	2,700	125	1,000	46	110	63	55	31	22	8.66	11	4.33
96	12.1	0.48	113	76	2,700	125	1,000	46	110	63	55	31	24	9.53	12.1	4.76
120	13.6	0.54	139	93	2,700	125	1,000	46	110	63	55	31	27	10.71	13.6	5.35
144	15	0.59	167	112	2,700	125	1,000	46	110	63	55	31	30	11.81	15	5.9
228	15.8	0.62	178	120	2,700	125	1,000	46	110	63	55	31	32	12.44	15.8	6.22
276	17	0.67	212	142	2,700	125	1,000	46	110	63	55	31	34	13.39	17	6.69
300	17.7	0.7	228	153	2,700	125	1,000	46	110	63	55	31	35	13.94	17.7	6.97

Part Number:

LT-DJBGEXX/BRN MG2XXX(06T2.00)

Cáp quang dùng cả trong nhà/ngoài trời,loại Loose Tube,Đa mốt, OM2, 50/125um,2 lõi quang,vỏ dơn PE,không có giáp bảo vệ,Màu đen (Chú ý: Nếu lắp ngoài trời phải luồn cáp trong ống)
Outdoor/Indoor, Loose Tube,Multimode, OM2, 50/125um, 2
Cores,Single PE Jacket, Non Armor,Black (Note: Using a conduit for outdoor)

Xuất Xứ: Korea
