Benefits

• Reduced insulation wall thickness, therefore a space-saving installation
• Multi-standard certification reduces part varieties and saves costs
• Cost-saving, easy installation due to omission of closed cable systems (suitable for open wiring)
• Longer cable connection possible between converter and drive due to low capacitance design
• UL TC-ER and c(UL) CIC/TC approval

Application range

• Connecting cable between frequency converter and motor
• For fixed installation and applications with occasional movements
• Areas at risk of explosion (class 1 division 2) in accordance with NEC articles 336, 501
• Plant construction
• Industrial machinery and machine tools

Product features

• Oil-resistant according to UL OIL RES I & II
• Flame-retardant according to CSA FT4
  UL Vertical-Tray Flame Test
• 90°C Wet or Dry; -40°C Cold Bend;
  -25°C Cold Impact
• Sunlight resistant (UV-resistant); direct burial (can be buried in the ground according to US standards)

Norm references / approvals

• UL TC-ER (exposed run) according to UL 1277
• Class 1 division 2 in accordance with NEC art. 336, 501
• Flexible motor supply cable according to UL
• c(UL) CIC/TC FT4; cRU AWM I/II A/B FT4
• CE (50V – 1kV)

Design

• Fine-wire, tin-plated copper conductor
• Core insulation: XLPE
• Aluminium-coated foil
• Screening braid made of tin-plated copper wires
• Outer sheath: Specially designed thermoplastic elastomer (TPE), black
