Benefits

• Allows much faster motion sequences which increases the economic efficiency of machines
• Suitable for use with rotary encoder programmes from leading manufacturers
• Thin, optimised weight and volume
• Durable under harsh conditions thanks to robust PUR sheath material
• Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
• Wide temperature range for applications in harsh climatic environments

Application range

• Connecting cable between servo controller and encoder/resolver
• Connecting cable between servo controller and tachometer generators
• In power chains or mobile machine parts
• Particularly in wet areas of machine tools and transfer lines
• Assembly and production lines, in all kinds of machines
• For indoor and outdoor use

Product features

• Dynamic drag chain performance:
  Acceleration up to 50 m/s².
  Travel speeds up to 5 m/s.
  Travel distances up to 100 m.
• Flame retardance:
  UL/CSA: VW-1, FT1
  IEC/EN: 60332-1-2
• Halogen-free materials
• Low-capacitance design
• Abrasion-resistant and notch-resistant
• Oil-resistant

Norm references / approvals

• UL AWM Style 20236
• CSA AWM IA/B; IIA/B FT 1
• UL File No. E63634
• For use in power chains: Please comply with assembly guideline appendix T3

Design

• Fine-wire or extra-fine wire, tin-plated copper conductor
• Core insulation: Polypropylene (PP)
• Cores (or core pairs) twisted in layers or bundles
• Refer to data sheet for more details
• Fleece wrapping
• Polyurethane (PUR) sheath, green (RAL 6018)
