ÖLFLEX® CHAIN 808 P
Highly flexible control cable with PVC core insulation and abrasion and oil resistant PUR sheath
ÖLFLEX® CHAIN 808 P – highly flexible control cable with PVC core insulation and abrasion- and oil-resistant PUR outer sheath
- Basic Line for light to medium stress in power chains
- Good oil resistance
Benefits
- Good combination of quality and price
- Compact design
- Durable under harsh conditions thanks to robust PUR sheath material
- Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
Application range
- In power chains or mobile machine parts
- Particularly in wet areas of machine tools and transfer lines
- Suitable for use in measuring, control and regulating circuits
- Assembly and production lines, in all kinds of machines
- In dry, damp and wet interiors
Product features
- Designed for 2 million alternating bending cycles and travel distances up to 10 metres
- High oil resistance
- Abrasion-resistant and notch-resistant
- Low-adhesive surface
Norm references / approvals
- Based on EN 50525-2-21
- For use in power chains: Please comply with assembly guideline appendix T3
Design
- Fine-wire, bare copper conductor
- Core insulation: PVC
- Cores twisted in layers
- Fleece wrapping
- Polyurethane sheath, grey (RAL 7001)
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- Black with white numbers acc. to VDE 0293-1
Conductor design
- Fine wire according to VDE 0295 class 5 / IEC 60228 class 5
Minimum bending radius
- For flexible use:
Chains in self-supporting non-gliding arrangements: 10 x outer diameter
In chains in gliding arrangements: 12 x outer diameter - Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- Core/Core: 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
Alternating bending cycles
- 2 million cycles
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 1027700 | 2 X 0.5 | 5.2 | 10 | 40 |
| 1027701 | 3 G 0.5 | 5.5 | 15 | 48 |
| 1027702 | 4 G 0.5 | 6 | 20 | 58 |
| 1027703 | 5 G 0.5 | 6.5 | 24 | 67 |
| 1027704 | 7 G 0.5 | 7.7 | 34 | 88 |
| 1027705 | 12 G 0.5 | 9.2 | 58 | 136 |
| 1027706 | 18 G 0.5 | 11 | 87 | 195 |
| 1027707 | 25 G 0.5 | 13.3 | 120 | 274 |
| 1027708 | 2 X 0.75 | 5.6 | 15 | 49 |
| 1027709 | 3 G 0.75 | 6 | 22 | 60 |
| 1027710 | 4 G 0.75 | 6.5 | 29 | 73 |
| 1027711 | 5 G 0.75 | 7. 1 | 37 | 86 |
| 1027712 | 7 G 0.75 | 8.5 | 51 | 117 |
| 1027713 | 12 G 0.75 | 10.3 | 87 | 181 |
| 1027714 | 18 G 0.75 | 12.2 | 130 | 259 |
| 1027715 | 25 G 0.75 | 14.8 | 181 | 363 |
| 1027716 | 2 X 1.0 | 5.9 | 19 | 58 |
| 1027717 | 3 G 1.0 | 6.3 | 29 | 72 |
| 1027718 | 4 G 1.0 | 6.9 | 39 | 88 |
| 1027719 | 5 G 1.0 | 7.5 | 48 | 104 |
| 1027720 | 7 G 1.0 | 9 | 67 | 142 |
| 1027721 | 12 G 1.0 | 10.9 | 115 | 221 |
| 1027722 | 18 G 1.0 | 13.2 | 173 | 324 |
| 1027723 | 25 G 1.0 | 15.7 | 240 | 445 |
| 1027724 | 2 X 1.5 | 6.5 | 29 | 74 |
| 1027725 | 3 G 1.5 | 6.9 | 43.2 | 93 |
| 1027726 | 4 G 1.5 | 7.6 | 58 | 114 |
| 1027727 | 5 G 1.5 | 8.5 | 72 | 139 |
| 1027728 | 7 G 1.5 | 10.3 | 101 | 189 |
| 1027729 | 12 G 1.5 | 12.3 | 173 | 295 |
| 1027730 | 18 G 1.5 | 14.9 | 259 | 429 |
| 1027731 | 25 G 1.5 | 17.9 | 360 | 597 |
| 1027732 | 3 G 2.5 | 8.4 | 72 | 145 |
| 1027733 | 4 G 2.5 | 9.3 | 96 | 179 |
| 1027734 | 7 G 2.5 | 12.7 | 168 | 218 |
| 1027737 | 4 G 4 | 11. 1 | 160 | 266 |
