ÖLFLEX® CLASSIC FD 810 CP
Highly flexible, shielded control cable with PVC insulation, inner sheath and abrasion- and oil-resistant PUR sheath
ÖLFLEX® CLASSIC FD 810 CP – power and control cable for use in power chains in harsh environmental conditions in EMC critical areas.
- Core Line for average duty power chain applications
- Good oil resistance
- EMC-compliant copper shielding
Benefits
- Tried-and-tested and reliable
- Various applications
- Durable under harsh conditions thanks to robust PUR sheath material
- Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
- Additional robustness thanks to inner sheath
- Copper braiding complies with EMC requirements and screens the cable against electromagnetic interference
Application range
- In power chains or mobile machine parts
- Particularly in wet areas of machine tools and transfer lines
- Power circuits for electrical equipment used in automation engineering
- Suitable for use in measuring, control and regulating circuits
- In dry, damp or wet interiors with normal mechanical stress conditions
Product features
- Designed for 5 million alternating bending cycles and travel distances up to 10 metres
- Flame-retardant (IEC 60332.1.2)
- High oil resistance
- Abrasion-resistant and notch-resistant
- EMC-compliant
- Low-adhesive surface
Norm references / approvals
- Core based on VDE 0245/0285
- Sheath based on VDE 0245/0285
- For use in power chains: Please comply with assembly guideline appendix T3
Design
- Extra-fine wire strand made of bare copper wires (class 6)
- Core insulation: PVC
- Cores twisted in short lay lengths
- Fleece wrapping
- PVC inner sheath
- Tin-plated copper braiding
- Polyurethane sheath, grey (RAL 7001)
