ÖLFLEX® ROBUST FD C
Highly flexible, shielded all-weather control cable with TPE sheath – resistant to a wide range of chemical media
ÖLFLEX® ROBUST FD C – halogen-free and shielded power and control cable for use in power chains in harsh environmental conditions.
- Extended line for high loads in power chains
- Good chemical resistance
Benefits
- Outstanding weather, ozone and UV resistance together with the wide temperature range enable versatile use for indoor and outdoor applications
- Resistant to contact with bio-oils, fats, waxes and their emulsions with a plant, animal or synthetic basis
- Good resistance to ammonia compounds and biogases
- Good resistance to cold and hot water as well as water-soluble cleaning and cooling agents
- Suitable for frequent steam cleaning
Application range
- Machine tool building, medical technology, laundries, car washing equipment, chemical industry, composting plants, sewage works
- Food and beverage industry, especially for production and processing of milk and meat products
- Assembly and production lines, in all kinds of machines
- For indoor and outdoor use
Product features
- Ozone-, UV- and weather-resistant according to EN 50396 and HD 605 S2
- Designed for 10 million alternating bending cycles and horizontal travel distances up to 100 metres
- Highly resistant to oil and chemicals
- Hydrolysis-resistant to warm and hot water
- Good chemical resistance to ester-based hydraulic fluids
- Flexible at temperatures down to -40 °C
Norm references / approvals
- Based on VDE 0250 / 0285
- Certified resistance to disinfectant and cleaning solutions used in food and beverage industry
- For use in power chains: Please comply with assembly guideline appendix T3
Design
- Extra-fine wire, tin-plated copper strands
- Core insulation made of TPE
- Cores twisted together in extremely short lay lengths
- Fleece wrapping
- Inner sheath made of TPE
- Tin-plated copper braiding
- Robust sheath made of special halogen-free TPE, black (RAL 9005)
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- black cores with printed white numbers (VDE 0293-1)
Conductor design
- Extra-fine wire according to VDE 0295, class 6 / IEC 60228 class 6
Minimum bending radius
- For flexible use:
7.5 x cable diameter
(at temperatures < 70°C)
10 x cable diameter
(at a max. temperature of 105°C) - Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- flexing: -40°C to +105°C
fixed installation: -50°C to +105°C - short-term: up to +120°C
Alternating bending cycles
- 10 million cycles
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 0026701 | 3 G 0.75 | 9.1 | 49.6 | 110 |
| 0026702 | 4 G 0.75 | 10.1 | 60.9 | 137 |
| 0026703 | 5 G 0.75 | 10.8 | 72.8 | 160 |
| 0026704 | 7 G 0.75 | 12.6 | 107.2 | 238 |
| 0026705 | 12 G 0.75 | 15 | 151.5 | 312 |
| 0026706 | 18 G 0.75 | 17.7 | 205.5 | 448 |
| 0026707 | 25 G 0.75 | 21.7 | 299.1 | 657 |
| 0026709 | 3 G 1.0 | 9.8 | 61. 1 | 125 |
| 0026716 | 7 G 1.0 | 13.9 | 132.3 | 278 |
| 0026717 | 12 G 1.0 | 16.1 | 189.1 | 370 |
| 0026721 | 3 G 1.5 | 10.9 | 79.8 | 163 |
| 0026722 | 4 G 1.5 | 12.1 | 99.2 | 210 |
| 0026723 | 5 G 1.5 | 13.6 | 129.7 | 264 |
| 0026724 | 7 G 1.5 | 15.8 | 175.2 | 370 |
| 0026725 | 12 G 1.5 | 18.4 | 257. 1 | 498 |
| 0026726 | 18 G 1.5 | 22.1 | 378.9 | 749 |
| 0026727 | 25 G 1.5 | 27. 1 | 555.5 | 1042 |
| 0026731 | 4 G 2.5 | 14.4 | 161.5 | 307 |
| 0026732 | 5 G 2.5 | 15.5 | 188.3 | 361 |
| 0026733 | 7 G 2.5 | 18.3 | 252.6 | 512 |
| 0026734 | 12 G 2.5 | 21.9 | 406.5 | 730 |
| 0026741 | 4 G 4 | 16.2 | 227.3 | 412 |
| 0026751 | 4 G 6 | 17.2 | 306.7 | 519 |
| 0026761 | 4 G 10 | 23.3 | 513.6 | 853 |
| 0026771 | 4 G 16 | 27.2 | 809.6 | 1273 |
