ÖLFLEX® FD 891
Highly flexible control cable with PVC core insulation and PVC sheath – certified for North America
ÖLFLEX® FD 891 – power and control cable for versatile use in power chains with UL/CSA AWM certification.
- Core Line for average duty power chain applications
- AWM certification for USA and Canada
Benefits
- Multi-standard certification reduces part varieties and saves costs
- Ideal for export-oriented machinery and equipment manufacturers
- Also suitable for flexing outdoor use due to the temperature range
Application range
- In power chains or mobile machine parts
- Suitable for use in measuring, control and regulating circuits
- Assembly and production lines, in all kinds of machines
- Machine tools
- Plant construction
Product features
- Designed for 5 million alternating bending cycles and travel distances up to 10 metres
- Flame-retardant according to IEC 60332-1-2 & CSA FT1
- Oil-resistant
- Low-adhesive surface
Norm references / approvals
- UL AWM Style 21098
- CSA AWM IA/B; IIA/B FT 1
- UL File No. E63634
- For use in power chains: Please comply with assembly guideline appendix T3
Design
- Extra-fine wire strand made of bare copper wires (class 6)
- Core insulation: PVC
- Cores twisted in layers with short lay lengths
- Fleece wrapping
- PVC sheath, black (RAL 9005)
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- Black with white numbers acc. to VDE 0293-1
Conductor design
- Extra-fine wire according to VDE 0295, class 6/IEC 60228 class 6
Minimum bending radius
- For flexible use:
7.5 x outer diameter - Fixed installation: 4 x outer diameter
Nominal voltage
- IEC: U0/U 300/500 V
- UL/CSA: 600 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Flexing: -5°C to +90°C (UL/CSA)
- Fixed installation: -40°C to +90°C (UL/CSA)
Alternating bending cycles
- 5 million cycles
| Article number | Number of cores and mm² per conductor |
Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 1026012 | 12 G 0.5 | 10.8 | 57.6 | 162 |
| 1026103 | 3 G 0.75 | 6.6 | 21.6 | 63 |
| 1026104 | 4 G 0.75 | 7.3 | 28.8 | 75 |
| 1026105 | 5 G 0.75 | 8 | 36 | 90 |
| 1026107 | 7 G 0.75 | 9.6 | 50.4 | 132 |
| 1026112 | 12 G 0.75 | 11.6 | 86.5 | 201 |
| 1026118 | 18 G 0.75 | 13.9 | 129.60 | 300 |
| 1026125 | 25 G 0.75 | 16.6 | 180.00 | 415 |
| 1026127 | 3 G 1.0 | 7. 1 | 28.80 | 65 |
| 1026129 | 4 G 1.0 | 7.8 | 39.00 | 82 |
| 1026130 | 5 G 1.0 | 8.8 | 48.00 | 105 |
| 1026128 | 7 G 1.0 | 10.5 | 67.20 | 149 |
| 1026131 | 12 G 1.0 | 12.5 | 116 | 225 |
| 1026132 | 18 G 1.0 | 15 | 173 | 331 |
| 1026133 | 25 G 1.0 | 17.9 | 240.00 | 484 |
| 1026303 | 3 G 1.5 | 7.7 | 43.20 | 93 |
| 1026304 | 4 G 1.5 | 8.8 | 57.60 | 122 |
| 1026305 | 5 G 1.5 | 9.6 | 72.00 | 147 |
| 1026307 | 7 G 1.5 | 11.6 | 100.80 | 219 |
| 1026312 | 12 G 1.5 | 13.9 | 172.80 | 322 |
| 1026318 | 18 G 1.5 | 16.9 | 259.20 | 478 |
| 1026325 | 25 G 1.5 | 20.1 | 360.00 | 670 |
| 1026334 | 34 G 1.5 | 23.6 | 489.60 | 897 |
| 1026403 | 3 G 2.5 | 8.8 | 72.00 | 129 |
| 1026404 | 4 G 2.5 | 9.8 | 96 | 167 |
| 1026405 | 5 G 2.5 | 11 | 120 | 212 |
| 1026407 | 7 G 2.5 | 13.4 | 168 | 304 |
| 1026412 | 12 G 2.5 | 15.8 | 288 | 452 |
| 1026504 | 4 G 4 | 11.8 | 153.6 | 263 |
| 1026505 | 5 G 4 | 13.2 | 192 | 325 |
| 1026507 | 7 G 4 | 16.1 | 268.8 | 469 |
| 1026604 | 4 G 6 | 13.7 | 230.4 | 368 |
| 1026614 | 4 G 10 | 17.9 | 384 | 588 |
| 1026624 | 4 G 16 | 24.1 | 614.4 | 1031 |
| 1026634 | 4 G 25 | 27.9 | 960 | 1530 |
| 1026644 | 4 G 35 | 31.1 | 1,344.00 | 1959 |
■ Accessories
▯ SILVYN® CHAIN cable protection and guiding systems
