ÖLFLEX® FD 891 P
Highly flexible control cable with PVC core insulation and abrasion and oil resistant PUR sheath – certified
ÖLFLEX® FD 891 P – oil-resistant power and control cable for power chain use in harsh conditions with UL/cUL AWM certification.
- Core Line for average duty power chain applications
- Good oil resistance
- AWM certification for USA and Canada
Benefits
- Multi-standard certification reduces part varieties and saves costs
- Durable under harsh conditions thanks to robust PUR sheath material
- Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
- Ideal for export-oriented machinery and equipment manufacturers
Application range
- In power chains or mobile machine parts
- Particularly in wet areas of machine tools and transfer lines
- Suitable for use in measuring, control and regulating circuits
- Plant construction
Product features
- Designed for 5 million alternating bending cycles and travel distances up to 10 metres
- Flame-retardant according to IEC 60332-1-2 & CSA FT1
- High oil resistance
- Abrasion-resistant and notch-resistant
- Low-adhesive surface
Norm references / approvals
- UL rec. AWM Style 20234
- cRU AWM II A/B FT 1
- UL File No. E63634
- For use in power chains: Please comply with assembly guideline appendix T3
Design
- Extra-fine wire strand made of bare copper wires (class 6)
- Core insulation: PVC
- Cores twisted in layers with short lay lengths
- Fleece wrapping
- Polyurethane sheath, black (RAL 9005)
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- Black with white numbers acc. to VDE 0293-1
Conductor design
- Extra-fine wire according to VDE 0295, class 6/IEC 60228 class 6
Minimum bending radius
- For flexible use:
7.5 x outer diameter - Fixed installation: 4 x outer diameter
Nominal voltage
- IEC: U0/U 300/500 V
- UL/CSA: 600 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Flexing: -5°C to +80°C (UL/CSA)
- Fixed installation: -40°C to +80°C (UL/CSA)
Alternating bending cycles
- 5 million cycles
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 1028752 | 2 X 0.5 | 6.5 | 9.6 | 46 |
| 1028007 | 7 G 0.5 | 9.6 | 33.6 | 118 |
| 1028103 | 3 G 0.75 | 7.3 | 21.6 | 66 |
| 1028104 | 4 G 0.75 | 8 | 28.8 | 82 |
| 1028105 | 5 G 0.75 | 8.7 | 36 | 101 |
| 1028107 | 7 G 0.75 | 10.7 | 50.4 | 142 |
| 1028112 | 12 G 0.75 | 11.7 | 86.40 | 196 |
| 1028118 | 18 G 0.75 | 13.9 | 129.60 | 282 |
| 1028125 | 25 G 0.75 | 16.6 | 180.00 | 404 |
| 1028134 | 34 G 0.75 | 18.9 | 244.80 | 541 |
| 1028150 | 50 G 0.75 | 22.5 | 360.00 | 738 |
| 1028303 | 3 G 1.5 | 8.4 | 43.20 | 98 |
| 1028304 | 4 G 1.5 | 9.3 | 57.6 | 125 |
| 1028305 | 5 G 1.5 | 10.1 | 72.00 | 155 |
| 1028307 | 7 G 1.5 | 11.9 | 100.80 | 221 |
| 1028312 | 12 G 1.5 | 13.9 | 172.80 | 318 |
| 1028318 | 18 G 1.5 | 16.9 | 259.20 | 484 |
| 1028325 | 25 G 1.5 | 20.1 | 360.00 | 671 |
| 1028334 | 34 G 1.5 | 23.1 | 489.60 | 910 |
| 1028952 | 2 X 2.5 | 8.9 | 48.00 | 102 |
| 1028403 | 3 G 2.5 | 9.3 | 72.00 | 134 |
| 1028404 | 4 G 2.5 | 10.3 | 96.00 | 173 |
| 1028405 | 5 G 2.5 | 11.3 | 120.00 | 217 |
| 1028407 | 7 G 2.5 | 13.4 | 168.00 | 312 |
| 1028412 | 12 G 2.5 | 15.8 | 288 | 460 |
| 1028503 | 3 G 4 | 10.9 | 115.2 | 197 |
| 1028504 | 4 G 4 | 12.1 | 153.6 | 257 |
| 1028507 | 7 G 4 | 16.1 | 268.8 | 471 |
| 1028604 | 4 G 6 | 13.7 | 230.4 | 363 |
| 1028614 | 4 G 10 | 17.9 | 384 | 605 |
| 1028624 | 4 G 16 | 23.4 | 614.4 | 973 |
| 1028634 | 4 G 25 | 27.6 | 960 | 1437 |
