ÖLFLEX® PETRO FD 865 CP
Halogen-free, highly flexible and shielded control cable with abrasion and MUD-resistant PUR sheath – certified
ÖLFLEX® PETRO FD 865 CP – halogen-free, oil-resistant and shielded power and control cable for use in power chains, complies with NEK 606.
- Extended line for high loads in power chains
- Resistant to oil and drilling fluids
according to NEK TS 606:2016 (Oil & Mud) - EMC-compliant copper shielding
Benefits
- Suitable for contact with oil- and ester-based drilling emulsions as well as calcium bromide solutions
- Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
- Suitable for long horizontal drag chain distances
- Additional robustness thanks to inner sheath
- Wide temperature range for applications in harsh climatic environments
- Copper braiding complies with EMC requirements and screens the cable against electromagnetic interference
Application range
- Permanently flexing power chains or machine parts in harsh environments
- Onshore and offshore applications
- In wet areas within machine tools and transfer, production or assembly lines
- For indoor and outdoor use
Product features
- Designed for 10 million alternating bending cycles and horizontal travel distances up to 100 metres
- Halogen-free and flame-retardant (IEC 60332-1-2)
- Good weather, ozone, UV and oil resistance
- Good notch and abrasion resistance
- Flexible at cold temperatures
- EMC-compliant
Norm references / approvals
- DNV Det Norske Veritas certified
- Resistant to oil and drilling fluids according to NEK TS 606:2016 and IEC 61892-4
- Salt water-resistant according to UL 1309
- For use in power chains: Please comply with assembly guideline appendix T3
Design
- Extra-fine wire strand made of bare copper
- Core insulation made of TPE
- Cores twisted in short lay lengths
- Fleece wrapping
- Inner sheath made of TPE
- Tin-plated copper braiding
- Outer sheath made of robust special polymer, colour black
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- Black with white numbers acc. to VDE 0293-1
Conductor design
- Extra-fine wire according to VDE 0295, class 6 / IEC 60228 class 6
Minimum bending radius
- For flexible use:
7.5 x outer diameter - Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 3000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Flexing: -50°C to +80°C
- Fixed installation: -60°C to +80°C
Alternating bending cycles
- 10 million cycles
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 0023300 | 2 X 0.5 | 6.7 | 32 | 67 |
| 0023301 | 3 G 0.5 | 7. 1 | 40 | 79 |
| 0023302 | 4 G 0.5 | 7.6 | 47 | 84 |
| 0023303 | 5 G 0.5 | 8.2 | 53 | 107 |
| 0023304 | 7 G 0.5 | 9.5 | 67 | 132 |
| 0023305 | 12 G 0.5 | 10.9 | 97 | 190 |
| 0023306 | 18 G 0.5 | 12.9 | 131.00 | 245 |
| 0023307 | 20 G 0.5 | 13.5 | 156.00 | 281 |
| 0023308 | 25 G 0.5 | 15.6 | 190.00 | 367 |
| 0023309 | 30 G 0.5 | 15.8 | 222.00 | 408 |
| 0023310 | 36 G 0.5 | 16.9 | 251.00 | 459 |
| 0023311 | 2 X 0.75 | 7.2 | 40.00 | 79 |
| 0023312 | 3 G 0.75 | 7.6 | 47 | 96 |
| 0023313 | 4 G 0.75 | 8.3 | 58.00 | 112 |
| 0023314 | 5 G 0.75 | 8.9 | 65.00 | 126 |
| 0023315 | 7 G 0.75 | 10.6 | 85.00 | 165 |
| 0023316 | 12 G 0.75 | 12.1 | 127.00 | 231 |
| 0023317 | 18 G 0.75 | 14.6 | 198.00 | 330 |
| 0023318 | 20 G 0.75 | 15.5 | 213.00 | 354 |
| 0023319 | 25 G 0.75 | 17.7 | 259.00 | 459 |
| 0023320 | 30 G 0.75 | 17.7 | 296.00 | 480 |
| 0023321 | 36 G 0.75 | 19.5 | 348.00 | 605 |
| 0023322 | 2 X 1.0 | 7.6 | 45.00 | 93 |
| 0023323 | 3 G 1.0 | 8.1 | 55.00 | 109 |
| 0023324 | 4 G 1.0 | 8.8 | 68 | 126 |
| 0023325 | 5 G 1.0 | 9.6 | 81 | 147 |
| 0023326 | 7 G 1.0 | 11.3 | 106 | 196 |
| 0023327 | 12 G 1.0 | 13.2 | 175 | 292 |
| 0023328 | 18 G 1.0 | 15.9 | 242 | 418 |
| 0023329 | 20 G 1.0 | 16.6 | 269 | 427 |
| 0023330 | 25 G 1.0 | 19.2 | 329 | 575 |
| 0023331 | 30 G 1.0 | 19.6 | 377 | 635 |
| 0023332 | 36 G 1.0 | 21.2 | 467 | 758 |
| 0023333 | 2 X 1.5 | 8.3 | 58 | 115 |
| 0023334 | 3 G 1.5 | 8.9 | 76 | 139 |
| 0023335 | 4 G 1.5 | 9.8 | 91.00 | 156 |
| 0023336 | 5 G 1.5 | 10.8 | 111 | 198 |
| 0023337 | 7 G 1.5 | 12.5 | 145.00 | 254 |
| 0023338 | 12 G 1.5 | 14.9 | 242.00 | 416 |
| 0023339 | 18 G 1.5 | 17.4 | 346 | 564 |
| 0023340 | 20 G 1.5 | 18.3 | 377 | 562 |
| 0023341 | 25 G 1.5 | 21.4 | 486 | 811 |
| 0023342 | 30 G 1.5 | 21.4 | 821 | 821 |
| 0023343 | 36 G 1.5 | 23.4 | 655 | 1066 |
| 0023344 | 2 X 2.5 | 9.8 | 73 | 129 |
| 0023345 | 3 G 2.5 | 10.7 | 110 | 194 |
| 0023346 | 4 G 2.5 | 11.7 | 136 | 234 |
| 0023347 | 5 G 2.5 | 12.8 | 180 | 293 |
| 0023348 | 7 G 2.5 | 15.6 | 246 | 418 |
| 0023349 | 12 G 2.5 | 18 | 377 | 629 |
| 0023350 | 18 G 2.5 | 21.5 | 569 | 912 |
| 0023351 | 20 G 2.5 | 22.7 | 582 | 850 |
| 0023352 | 25 G 2.5 | 26.5 | 765 | 1266 |
| 0023353 | 4 G 4 | 13.9 | 205 | 311 |
| 0023354 | 5 G 4 | 15.4 | 250 | 381 |
| 0023355 | 4 G 6 | 16.2 | 289 | 423 |
| 0023356 | 5 G 6 | 17.8 | 354 | 512 |
| 0023357 | 4 G 10 | 20.4 | 475 | 672 |
| 0023358 | 5 G 10 | 22.3 | 582 | 814 |
