Benefits

• Allows much faster motion sequences which increases the economic efficiency of machines
• Multi-standard certification reduces part varieties and saves costs
• Durable under harsh conditions thanks to robust PUR sheath material
• Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
• Longer installation lengths thanks to low capacitance cable design
• Wide temperature range for applications in harsh climatic environments

Application range

• In power chains or mobile machine parts
• Applications in electrical and electronic automation engineering
• Power circuits in industrial machines
• For use in assembly & automatic placement machines
• Particularly in wet areas of machine tools and transfer lines
• For indoor and outdoor use

Product features

• Dynamic drag chain performance:
  Acceleration up to 50 m/s².
  Travel speeds up to 5 m/s.
  Travel distances up to 100 m.
• Flame retardance:
  UL/CSA: VW-1, FT1
  IEC/EN: 60332-1-2
• Halogen-free materials
• High oil resistance
• Low-capacitance design
• Flexible at temperatures down to -40 °C

Norm references / approvals

• VDE – reg. – no. 8661
  UL AWM Style 20234
  cULus AWM I/II A/B, 1000V 80° FT1
  CSA AWM I/II A, 1000V 80° FT1
• UL File No. E63634
• For use in power chains: Please comply with assembly guideline appendix T3

Design

• Extra-fine wire strand made of bare copper wires (class 6)
• Core insulation: Polypropylene (PP)
• Fleece wrapping
• Polyurethane sheath, black (RAL 9005)
