Input

• Input Connections

  —

Surge Protection and Filtering

• Data Line Protection

  RJ45 10/100/1000 Base-T Ethernet protection

• Data Lines Protected
  (multi-line only)

  1-8

• ts_nm_surge_response

  1ns

• Peak Current Common Mode

  0.25kAmps

• Peak Current Normal Mode

  6.5kAmps

Physical

• Maximum Height

  104mm , 10.4cm

• Maximum Width

  47mm , 4.7cm

• Maximum Depth

  28mm , 2.8cm

• Net Weight

  0.05kg

• Shipping weight

  0.11kg

• Shipping Height

  104mm , 10.4cm

• Shipping Width

  90mm , 9.0cm

• Shipping Depth

  29mm , 2.9cm

• Color

  Beige

• Master Carton Dimensions (Length x Width x Height)

  522 x 582 x 434mm

• Master Carton Units

  144.0

• Master Carton Weight

  21.0

• Units per Pallet

  1152.0

• SCC Codes

  1073130422673 1

Environmental

• Operating Environment

  -15 – 65 °C

• Operating Relative Humidity

  0 – 95 %

• Storage Temperature

  -15 – 65 °C

• Storage Relative Humidity

  0 – 95 %

Conformance

• Approvals

  UL 497B

• Standard warranty

  10 years repair or replace

Sustainable Offer Status

• RoHS

  Compliant

• REACH

  REACH: Contains No SVHCs

• Other Environmental Compliance

  China RoHS

DATA SHEET
