Protects an ethernet data port from damaging transients. Supports Cat5, Cat5E and Cat6 cabling standards. Compatible with Power Over Ethernet (POE) and network speeds up to 10GbE (10GigE).

Output

• Number of Outlets

  1.0

Surge Protection and Filtering

• Data Line Protection

  RJ45 10/100/1000 Base-T Ethernet protection

• Data Lines Protected
  (multi-line only)

  1

• Peak Current Common Mode

  0.25kAmps

• Peak Current Normal Mode

  0.2kAmps

Physical

• Maximum Height

  44mm , 4.4cm

• Maximum Width

  19mm , 1.9cm

• Maximum Depth

  69mm , 6.9cm

• Rack Height

  1U

• Net Weight

  0.02kg

• Shipping weight

  0.04kg

• Shipping Height

  99mm , 9.9cm

• Shipping Width

  33mm , 3.3cm

• Shipping Depth

  95mm , 9.5cm

• Color

  Black

• Master Carton Dimensions (Length x Width x Height)

  638 x 413 x 207mm

• Master Carton Units

  96.0

• Master Carton Weight

  6.01

• SCC Codes

  3073130421718 4

Environmental

• Operating Environment

  -15 – 45 °C

• Operating Relative Humidity

  0 – 95 %

• Operating Elevation

  0-3000meters

• Storage Temperature

  -15 – 45 °C

• Storage Relative Humidity

  0 – 95 %

• Storage Elevation

  0-3000meters

Conformance

• Approvals

  UL 497B, UL Recognized

• Standard warranty

  Lifetime

DATA SHEET
