Input

• Input Connections

  —

• Number of Power Cords

  1

Surge Protection and Filtering

• Data Line Protection

  RJ-45 Modem/Fax/DSL protection (four wire dual line)

• Data Lines Protected
  (multi-line only)

  3-6 RJ45

• ts_nm_surge_response

  1ns

• Peak Current Common Mode

  0.15kAmps

• Peak Current Normal Mode

  0.2kAmps

Physical

• Maximum Height

  103mm , 10.3cm

• Maximum Width

  47mm , 4.7cm

• Maximum Depth

  28mm , 2.8cm

• Net Weight

  0.06kg

• Shipping weight

  0.14kg

• Shipping Height

  104mm , 10.4cm

• Shipping Width

  90mm , 9.0cm

• Shipping Depth

  29mm , 2.9cm

• Color

  Beige

• Master Carton Units

  144.0

• Units per Pallet

  750.0

• SCC Codes

  10731304000430

Environmental

• Operating Environment

  -15 – 45 °C

• Operating Relative Humidity

  0 – 95 %

• Storage Temperature

  -15 – 45 °C

• Storage Relative Humidity

  0 – 95 %

Conformance

• Approvals

  UL 497A, UL Listed

• Standard warranty

  10 years repair or replace

Sustainable Offer Status

• RoHS

  Compliant

• Other Environmental Compliance

  China RoHS
