APC ( PTEL2R ) Card module Chống Sét cho Đường dây điện thoại 1U, sử dụng với Khung gầm Rackmount PRM4 hoặc PRM24
APC Surge Module for Analog Phone Line, Replaceable, 1U, use with PRM4 or PRM24 Rackmount Chassis
PTEL2R
Output
-
Number of Outlets
1.0
Surge Protection and Filtering
-
Data Line Protection
Analog phone line for phone/fax/modem/DSL (RJ-45 connector)
-
Data Lines Protected
(multi-line only)Dual analog line (4 wire)
-
ts_nm_surge_response
1ns
-
Peak Current Common Mode
0.25kAmps
-
Peak Current Normal Mode
0.2kAmps
Physical
-
Maximum Height
44mm , 4.4cm
-
Maximum Width
19mm , 1.9cm
-
Maximum Depth
69mm , 6.9cm
-
Net Weight
0.02kg
-
Shipping weight
0.05kg
-
Shipping Height
99mm , 9.9cm
-
Shipping Width
33mm , 3.3cm
-
Shipping Depth
95mm , 9.5cm
-
Color
Black
-
Master Carton Units
96.0
-
Units per Pallet
28.0
-
SCC Codes
3073130420285 2
Environmental
-
Operating Environment
-15 – 45 °C
-
Operating Relative Humidity
0 – 95 %
-
Operating Elevation
0-3000meters
-
Storage Temperature
-15 – 45 °C
-
Storage Relative Humidity
0 – 95 %
-
Storage Elevation
0-3000meters
Conformance
-
Approvals
cUL Recognized, CE, UL 497A
-
Standard warranty
Lifetime
Sustainable Offer Status
-
RoHS
Compliant
-
Other Environmental Compliance
China RoHS
DATA SHEET
