Output

• Number of Outlets

  5.0

• Receptacle Style

  Universal

Input

• Nominal Input Voltage

  230V

• Input frequency

  47 – 63 Hz

• Input Connections

  NEMA 5-15P

• Cord Length

  1.83meters

• Number of Power Cords

  1

• Maximum Input Current

  10.0A

Surge Protection and Filtering

• Surge energy rating

  480Joules

• Data Line Protection

  —

• Data Lines Protected
  (multi-line only)

  —

• ts_nm_surge_response

  1ns

• Peak Current Common Mode

  19.5kAmps

• Peak Current Normal Mode

  20kAmps

Physical

• Maximum Height

  42mm , 4.2cm

• Maximum Width

  363mm , 36.3cm

• Maximum Depth

  178mm , 17.8cm

• Net Weight

  0.73kg

• Shipping weight

  0.84kg

• Shipping Height

  1245mm , 124.5cm

• Shipping Width

  363mm , 36.3cm

• Shipping Depth

  178mm , 17.8cm

• Color

  Black

• Master Carton Dimensions (Length x Width x Height)

  386 x 347 x 402mm

• Master Carton Units

  12.0

• Master Carton Weight

  12.5

• SCC Codes

  1073130429217 0

Environmental

• Operating Environment

  0 – 40 °C

• Operating Relative Humidity

  0 – 95 %

• Storage Temperature

  -40 – 85 °C

• Storage Relative Humidity

  0 – 95 %

Conformance

• Equipment protection policy

  No EPP for ASEAN

• Standard warranty

  10 years repair or replace

Sustainable Offer Status

• RoHS

  Compliant

• REACH

  REACH: Contains No SVHCs
