Output

• Number of Outlets

  1.0

• Receptacle Style

  IEC 320-C8

Input

• Nominal Input Voltage

  230V

• Input frequency

  50/60 Hz +/- 5 Hz (auto sensing)

• Input Connections

  IEC 320 C8

• Number of Power Cords

  1

• Input Power

  575.0Watts

• Maximum Line Current

  4A

Surge Protection and Filtering

• Surge energy rating

  180Joules

• Data Line Protection

  RJ-11 Modem/Fax protection (two wire single line), RJ45 10/100 Base-T Ethernet protection

• ts_nm_surge_response

  1ns

• Peak Current Normal Mode

  6.5kAmps

Physical

• Maximum Height

  27mm , 2.7cm

• Maximum Width

  32mm , 3.2cm

• Maximum Depth

  98mm , 9.8cm

• Net Weight

  0.1kg

• Shipping weight

  0.2kg

• Shipping Height

  66mm , 6.6cm

• Shipping Width

  158mm , 15.8cm

• Shipping Depth

  192mm , 19.2cm

• Color

  Silver

• Master Carton Units

  12.0

• Units per Pallet

  480.0

Environmental

• Operating Environment

  0 – 40 °C

• Operating Relative Humidity

  0 – 95 %

• Operating Elevation

  0-3000meters

• Storage Temperature

  -15 – 45 °C

• Storage Relative Humidity

  0 – 95 %

• Storage Elevation

  0-9000meters

Conformance

• Approvals

  A-tick, CE, CSA, FCC Part 68, GS Mark, NOM, Telepermit, UL Listed, VDE

• Equipment protection policy

  Lifetime : $75000, Lifetime : 75000 Euros, Lifetime : 50000 GBP

• Standard warranty

  5 years (all other countries), Lifetime (European Union countries only)

Sustainable Offer Status

• RoHS

  Compliant
