ÖLFLEX® ROBOT 900 P
TPE-PUR robot cable for bending and torsion load
ÖLFLEX® ROBOT 900 P – power and control cable for bending and torsional loads in harsh environmental conditions.
- Simultaneous bending and twisting
- Torsion angle up to +/- 360 °/m
Benefits
- Allows much faster motion sequences which increases the economic efficiency of machines
- Space-saving due to small cable diameters
- Durable under harsh conditions thanks to robust PUR sheath material
- Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
- Wide temperature range for applications in harsh climatic environments
Application range
- Plant construction
- Industrial machinery and machine tools
- Automated handling equipment
- Multi-axis articulated robot
- In power chains or mobile machine parts
Product features
- Abrasion-resistant and notch-resistant
- Flame-retardant
- High oil resistance
- Flexible at cold temperatures
- Low-adhesive surface
Norm references / approvals
- For distances up to 10 m
- For use in power chains: Please comply with assembly guideline appendix T3
Design
- Fine or extra-fine strands made of bare copper wire
- Core insulation made of TPE
- Cores twisted in layers
- Versions with additional core pair:
2 cores twisted to a pair, PTFE tape wrapping, coating of tin-plated copper wires, PUR inner sheath - Wrapping: PTFE tape
- Polyurethane sheath, black (RAL 9005)
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- Up to 0.34 mm²: Cores DIN 47100
- From 0.5 mm²: black cores with white printed numbers
Operating capacitance
- C/C approx. 100 nF/km
- C/S approx. 120 nF/km
Peak operating voltage
- 0.34 mm²: 350 V (not for power applications)
Inductance
- approx. 0.7 mH/km
Conductor design
- Fine wire or extra-fine wire
Torsion
- Torsion load max. ± 360 °/m
Minimum bending radius
- Flexing: 15 x outer diameter
- Fixed installation: 4 x outer diameter
Nominal voltage
- up to 0.34 mm²: 48 V AC
- from 0.5 mm² U0/U: 300/500 V
Test voltage
- Up to 0.34 mm²: 1500 V
- from 0.5 mm²: 3000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Flexing: -40°C to +80°C
Fixed installation: -50°C to +80°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 0028110 | 7 X 0.25 | 6.2 | 16.8 | 48 |
| 0028116 | 25 X 0.25 | 10.2 | 60 | 141 |
| 0028188 | 2 X 0.34 | 5 | 7 | 27 |
| 0028145 | 18 G 0.5 | 11.2 | 86.4 | 120 |
| 0028146 | 25 G 0.5 | 13.3 | 120 | 254 |
| 0028160 | 4 G 0.75 | 6.6 | 28.8 | 63 |
| 0028164 | 14 G 0.75 | 11.2 | 100.8 | 199 |
| 0028170 | 2 X 1.0 | 6.2 | 19.2 | 47 |
| 0028171 | 3 G 1.0 | 6.5 | 29 | 61 |
| 0028172 | 4 G 1.0 | 7 | 38.4 | 76 |
| 0028174 | 7 G 1.0 | 9.3 | 67.2 | 131 |
| 0028176 | 12 G 1.0 | 11.5 | 115.2 | 216 |
| 0028185 | 16 G 1,0 + (2 x 1,0) | 16 | 195 | 376 |
| 0028178 | 18 G 1.0 | 13.2 | 172.8 | 287 |
| 0028186 | 23 G 1,0 + (2 x 1,0) | 17.3 | 262 | 470 |
| 0028180 | 25 G 1.0 | 16.4 | 240 | 433 |
| 0028190 | 34 G 1.0 | 19.9 | 326.4 | 571 |
| 0028191 | 41 G 1.0 | 22.3 | 393.6 | 705 |
| 0028198 | 18 G 1.5 | 15.8 | 259.2 | 446 |
| 0028181 | 3 G 2.5 | 9.3 | 72 | 136 |
| 0028182 | 4 G 2.5 | 10.1 | 96 | 171 |
| 0028400 | 3 G 16 | 21.4 | 460.8 | 721 |
| 0028187 | 3 G 25 | 26.2 | 720 | 1178 |
| 0028189 | 3 G 35 | 28.8 | 1,008.00 | 1559 |
