Bộ Chuyển Đổi 3Onedata ( Model1200 ) 2-port 10/100M Ethernet Media Converter

09
Th5

Model : Model1200

The Media Converter complies with IEEE802.3, IEEE802.3u, IEEE802.3x Standards. It is designed to convert data signal between 10/100 Base-TX and 100Base-FX fast Ethernet. It supports 10/100Base-TX and 100Base-FX applications. The data signal converted by such high performance media converter can be transmitted up to 120Km maximum by fiber-optical cable. The Converter is equipped one optic port and two RJ45 Jacks and one external power supply receptacle. Four LED indicators are built-in for easy diagnosing and monitoring the status of. It can be configured automatically for Full Duplex or Half Duplex operation.
Features

1. Accord to IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3 100Base-FX
2. MDI/MDI-X auto negotiation, 10M/100M auto negotiation
3. Supports full /half duplex, Point-to-point transparent transfer
4. Power External 5VDC input
5. Plug-and-play, easy to installation
6. Can insert to 2U 19″, 14 slots Rackmount

Specification

Standards: comply with IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3 100Base-FX
RJ45 port rate: 10/100Mbps auto negotiation
Optic port rate: 100Mbps
Working: Asynchronous, point to point
Transfer distance: RJ45port: 100m
Fiber optic:20,40,60,80,100,120km(SM), 2 km(MM) optional
RJ45 port cable: UTP 5E
Fiber connector: SC, ST, FC optional
Fiber optic cables: Single Mode:8.3/125,8.7/125,9/125 or 10/125 um
Muti-Mode:50/125,62.5/125 um
Wavelength:850nm,1310nm,1550nm
Power
Power supply: External 5VDC input
Consumption: 4W
Environment
Operating temp:-10°C to 60°C
Storage temperature: -20 to 70°C
Operating humidity: 5% to 95%(no condensation)
Appearance
Dimensions: 94.0×71.0×26.0mm(external power supply)
Shell: Iron
Color: White
Weight: 230g(external power supply)
Warranty: 3 years
Approvals: FCC,CE, RoHS approvals

Dimension

Ordering Information
Model1200-MM:
2-port 10/100Base-T(X) + 1-port 100Base-FX Multi-mode SC/ST/FC, 5VDC
Model1200-SM:
2-port 10/100Base-T(X) + 1-port 1000Base-FX Single-mode SC/ST/FC, 5VDC
Model1200-SS:
2-port 10/100Base-T(X) + 1-port 1000Base-FX Single-mode, single fiber SC/ST/FC, 5VDC
