Chassis 3Onedata ( RACK2000A ) 14 Slots Ethernet Media Converter Rack

Model : RACK2000A

RACK2000A for Media converter adapt integration management media converter Rack in machine room. Each Rack have 14 insert slots, can insert 1-14 different media converters. Redundant Power Supply, support hot-swappable, provide credibility, high effect and economic solutions for network system.
Features

1.Adopt insert-draw design, Easy to load and unload, Plug-and-play, support hot-swappable
2. Each Rack have 14 insert slots, can insert 1-14 different media converters, high capability, easy to upgrade
3. Full aluminums metal shell, high shield, high anti-jamming
4. Adopt auto-adapt technology. Do not adjust electrics and optics when installation
5. Redundant Power Supply, Low consumption, and credibility
6. Full working indicator light, easy to maintenance

Specification

Parameter
Working Temperature:0°C to 55°C
Storage Temperature:-40°C to 85°C
Relative Humidity:5%~95%
Dimension:482.6mm×350mm×88mm(L×W×H)
19 Inch 2U
Power supply Require
Input:AC  100~260V,50~60HZ, or DC -48V
Out put:DC +5V
Consumption:<60W
Wave:≤50mv
Noise:≤50mv
Warranty: 3 years
Approvals: FCC, CE, RoHS approvals

Dimension

Ordering Information
RACK2000A:
14 Slots Ethernet Media Converter Rack with dual power supply, 2U 19″, AC/DC optional
