Model : RACK2000C
Adopt double power supply to supply power at the same time. Lighten the charge of each power supply, extend the life of the power supply. If one power supply fault. Another power supply can supply independence, media converter can work no-stop. When maintain and instead the power supply, do not draw the media converter card, also do not remove the rack from the tank, just draw fault power supply from the back of the Rack, it is convenience to repair or instead.
1. Adopt insert-draw design, Easy to load and unload, Plug-and-play, support hot-swappable
2. Support WEB, SNMP, Telnet managed; 19 inch 2U, easy to install
3. Each Rack have 16 insert slot, can insert 1-16 different media converter modules, high capability, easy to upgrade
4. Full aluminums metal shell, high shield, high anti-jamming
5. Adopt auto-adapt technology. Do not adjust electrics and optics when installation
6. Redundant Power Supply, Low consumption, and credibility
7. Full working indicator light, easy to maintenance
Parameter
Working Temperature：0°C to 55°C
Storage Temperature：-40°C to 85°C
Relative Humidity：5%~95%
Dimension：425mm×315mm×92mm（L×W×H）
19 Inch 2U
Power supply Require
Input：AC 100~260V，50~60HZ, or DC -48V
Out put：DC +5V
Consumption：＜60W
Wave：≤50mv
Noise：≤50mv
Warranty: 3 years
Approvals: FCC, CE, RoHS approvals
Packing List
1. RACK2000C×1
2. 220V power line ×2
3. User manual ×1
