Model : SW485C
2. Port-powered, high efficiency obtain electricity, can also worked on 3 lines
3. RS-232 to RS-485 or RS-232 to RS-422
4. Lowest consumption
5. Automatic send data control, auto distinguish and sense direction adopt data transfer
6. Auto sense serial signal rate, zero delay automatic transmit
Standards: EIA RS-232C, RS-485,RS-422 standard
RS-232 signal: TX, RX, GND
RS-422 signal: T+, T-, R+, R-, GND
RS-485 signal: D+, D-, GND
Working mode: Asynchronism, point to point or multi point, 2 wire half-duplex,4 wire full duplex
Baud rate: 300~115200bps, auto test serial signal rate detect signal speed automatically, zero delay time
Flow control: Data direction auto-turnaround, no flow control is required
Transfer distance: RS-485/422 side:1.2Km,115200bps
RS-232 side: no less than 5m
Max number of drops: 128 nodes
Optical isolation: 2500V
Port protect: 1500W surge protection,15KV ESD protection
Connector: RS-232 side DB9 female
RS-485/422 side DB9M( DB9F to 5 bit terminal block)
Power
Power input: No power supply need, powered from TXD, RTS,DTR
Consumption: Static less than 10mA, dynamic less than 40mA
Environment
Operating temperature: -40°C to 80°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95%(no condensation)
Appearance
Dimensions: 95.0mm×33.0mm×16.5mm
Material: Plastic(shell)
Weight: 50g
Warranty: 3 years
Approvals: FCC,CE,RoHS approvals
