Power and control cables
Various applications
PVC outer sheath and numbered cores
LAPP KABEL ÖLFLEX® CLASSIC 110 BLACK 0,6/1 kV
ÖLFLEX® CLASSIC 110 BLACK 0.6/1 kV power and control cable for various applications, PVC, class 5, number-coded, outdoor use and burial
Good outdoor performance
Application range
- Plant construction
Machine building
Heating and air-conditioning systems
Power plant engineering
Event equipment - For fixed installation as well as occasional flexing with free, non-continuously recurring movement without tensile load
- Enhanced suitability for direct burial in ground
- Suitable for torsional applications which are typical for the loop in wind turbine generators (WTG)
Product features
- Flame-retardant according to IEC 60332-1-2
- UV and weather-resistant according to ISO 4892-2
- Ozone-resistant according to EN 50396
Norm references / approvals
- Based on VDE 0250-1 and HD 627-1 S1
Design
- Finely stranded bare copper wires
- PVC core insulation LAPP P8/1
- PVC sheath, black (RAL 9005)
■ Technical data
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- Black with white numbers acc. to VDE 0293-1
Conductor design
- Fine wire according to VDE 0295,
class 5 / IEC 60228 class 5
Torsion movement in WTG
- TW-0 & TW-1, refer to Appendix T0
Minimum bending radius
- Static/Occ. moved: 4/15xOD*
Nominal voltage
- U0/U: 600/1000 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Occasional flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
| Article number |
Number of cores and mm² per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| ÖLFLEX® CLASSIC 110 BLACK | ||||
| 1120232 | 2 X0.75 | 8,3 | 14,4 | 81 |
| 1120233 | 3 G0.75 | 8,7 | 21,6 | 93 |
| 1120234 | 3 X0.75 | 8,7 | 21,6 | 93 |
| 1120235 | 4 G0.75 | 9,2 | 29 | 108 |
| 1120237 | 5 G0.75 | 9,9 | 36 | 126 |
| 1120241 | 7 G0.75 | 10,7 | 51 | 162 |
| 1120248 | 12 G0.75 | 13,4 | 86 | 236 |
| 1120251 | 18 G0.75 | 15,4 | 130 | 334 |
| 1120259 | 41 G0.75 | 21,6 | 296 | 713 |
| 1120266 | 2 X1.0 | 8,6 | 19,2 | 98 |
| 1120267 | 3 G1.0 | 9 | 29 | 112 |
| 1120268 | 3 X1.0 | 9 | 29 | 112 |
| 1120269 | 4 G1.0 | 9,6 | 38,4 | 131 |
| 1120270 | 4 X1.0 | 9,6 | 38,4 | 131 |
| 1120271 | 5 G1.0 | 10,4 | 48 | 152 |
| 1120274 | 7 G1.0 | 11,1 | 67 | 196 |
| 1120280 | 12 G1.0 | 14 | 116 | 286 |
| 1120284 | 18 G1.0 | 16,1 | 173 | 419 |
| 1120290 | 25 G1.0 | 18,6 | 240 | 572 |
| 1120294 | 34 G1.0 | 21,3 | 326 | 764 |
| 1120298 | 41 G1.0 | 23,2 | 394 | 891 |
| 1120306 | 2 X1.5 | 9,6 | 29 | 123 |
| 1120307 | 3 G1.5 | 10,1 | 43 | 144 |
| 1120308 | 3 X1.5 | 10,1 | 43 | 144 |
| 1120309 | 4 G1.5 | 10,8 | 58 | 170 |
| 1120311 | 5 G1.5 | 11,7 | 72 | 199 |
| 1120314 | 7 G1.5 | 12,6 | 101 | 261 |
| 1120320 | 12 G1.5 | 16,1 | 173 | 399 |
| 1120322 | 14 G1.5 | 17 | 202 | 448 |
| 1120324 | 18 G1.5 | 18,8 | 259 | 547 |
| 1120328 | 25 G1.5 | 21,7 | 360 | 770 |
| 1120330 | 34 G1.5 | 24,9 | 490 | 996 |
| 1120333 | 50 G1.5 | 29,8 | 720 | 1427 |
| 1120339 | 2 X2.5 | 10,8 | 48 | 147 |
| 1120340 | 3 G2.5 | 11,3 | 72 | 182 |
| 1120342 | 4 G2.5 | 12,2 | 96 | 225 |
| 1120343 | 4 X2.5 | 12,2 | 96 | 225 |
| 1120344 | 5 G2.5 | 13,3 | 120 | 266 |
| 1120346 | 7 G2.5 | 14,4 | 168 | 354 |
| 1120349 | 12 G2.5 | 18,7 | 288 | 540 |
| 1120350 | 14 G2.5 | 19,8 | 336 | 542 |
| 1120351 | 18 G2.5 | 22 | 432 | 788 |
| 1120353 | 25 G2.5 | 25,8 | 600 | 1094 |
| 1120360 | 4 G4 | 13,8 | 154 | 324 |
| 1120361 | 5 G4 | 15,1 | 192 | 385 |
| 1120362 | 7 G4 | 16,4 | 269 | 513 |
| 1120366 | 4 G6 | 15,1 | 230 | 442 |
| 1120367 | 5 G6 | 16,8 | 288 | 526 |
| 1120368 | 7 G6 | 18,2 | 403 | 705 |
| 1120370 | 4 G10 | 18,7 | 384 | 707 |
| 1120371 | 5 G10 | 20,7 | 480 | 881 |
| 1120374 | 4 G16 | 21,3 | 614 | 1100 |
| 1120375 | 5 G16 | 23,6 | 768 | 1600 |
| 1120376 | 7 G16 | 26,2 | 1,075.0 | 1890 |
| 1120378 | 4 G25 | 26,2 | 960 | 1600 |
| 1120379 | 5 G25 | 29 | 1,200.0 | 2050 |
| 1120382 | 4 G35 | 29,1 | 1,344.0 | 2400 |
| 1120383 | 5 G35 | 32,5 | 1,680.0 | 2900 |
| 1120385 | 4 G50 | 35,6 | 1,920.0 | 3400 |
| 1120387 | 4 G70 | 40,7 | 2,688.0 | 5050 |
| 1120389 | 4 G95 | 46,8 | 3,648.0 | 6010 |
| 1120390 | 4 G120 | 53,5 | 4,608.0 | 7500 |
