Bộ chuyển đổi 3Onedata ( USB8232I ) USB to 8 port RS-232 Converter with Isolation

09
Th5

Model : USB8232I

USB8232I is a kind of USB to 8 port RS-232 converter, the USB8232I can let PC or work station’s USB port connect 8pcs RS-232 comfortable. USB8232I provides 8 RS-232 serial ports, is compliant with USB 1.1 and 2.0 specifications, and meet the 480Mbps high-speed requirement of Hi-Speed USB 2.0. Using your computer’s USB ports to connect serial devices reduces the total cost of ownership, investment in hardware, and long term management and integration costs.
Features
1.USB to 8 port RS-232 Converter
2.CPU occupancy rate very low, high performance
3.RS-232 side transfer distance 15m
4.RS-232 support 2KVAC isolation
5.Detect serial speed automatic, Speed: 300～115200bps
6.Industrial grade design, IP30 protection
7.No fan, low consumption design
8.Working temperature: -40℃～85℃, Relative humidity: 5%-95%

Specification

Parameter
Serial port: 8 port RS-232
RS-232 signal: DCD, RXD, TXD, DTR, GND, DSR, RTS, CTS
Parity: None,Even,Odd,Space,Mark
Data: 7bit,8bit
Stop bit: 1bit,2bit
Band rate: 300bps～115200bps
Direction: ADDC, auto detect direction control
Protection: 2KVAC isolation, grade 4 static protection
Distance: RS-232 side: 15m, USB side less than 5m
Interface
USB port: USB female, type B
RS-232 port: DB9 male
LED indicator
Power indicator: PWR
8 port RS-232 COM1~COM8 send data: TX1~TX8
8 port RS-232 COM1~COM8 receive data: RX1~RX8
Power supply

Power input: 9VDC
No-load power consumption:1.63W@9VDC
Full-load power consumption:2.13W@9VDC
Mechanical:
Shell: IP30, high strength iron shell.
Weight: 1011g
Dimension(L×W×H):230mm×148.3mm×40mm
Environmental
Working temperature: -40～85℃
Storage temperature: -40～85℃
Ambient Relative Humidity:
10 to 95% (non-condensing)
Standard
EMS: EN61000-4-2 (ESD), Level 4
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Warranty:
Warranty time: 3 years
Certification：
CE, FCC, RoHS, UL508(Pending)

Dimension

Ordering Information
USB8232I:
USB to 8-port RS-232 Converter, 2KV Isolation, 9VDC
