Power and control cables
Various applications
PVC outer sheath and numbered cores
LAPP KABEL ÖLFLEX® CLASSIC 110 CY BLACK 0,6/1 kV
ÖLFLEX® CLASSIC 110 CY 0.6/1 kV power and control cable for various applications, PVC, class 5, number-coded, shielded and outdoor use
- Good outdoor performance
- EMC/shielded
Application range
- Plant construction
Machine building
Heating and air-conditioning systems
Power plant engineering - For frequency converter-powered three-phase machines
- In EMC-sensitive environments
(electromagnetic compatibility) - For fixed installation as well as occasional flexing with free, non-continuously recurring movement without tensile load
- Enhanced suitability for direct burial in ground
Product features
- Flame-retardant according to IEC 60332-1-2
- UV and weather-resistant according to ISO 4892-2
- Ozone-resistant according to EN 50396
- High level of screening
Low coupling resistance
(max. 250 Ω/km at 30 MHz)
Norm references / approvals
- Based on VDE 0250-1 and HD 627-1 S1
Design
- Finely stranded bare copper wires
- PVC core insulation LAPP P8/1
- PVC inner sheath, black
- Tinned-copper braiding
- PVC sheath, black (RAL 9005)
■ Technical data
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- Black with white numbers acc. to VDE 0293-1
Conductor design
- Fine wire according to VDE 0295,
class 5 / IEC 60228 class 5
Minimum bending radius
- Static/Occ. moved: 6/20xOD*
Nominal voltage
- U0/U: 600/1000 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Occasional flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
| Article number |
Number of cores and mm² per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| ÖLFLEX® CLASSIC 110 CY BLACK | ||||
| 1121232 | 2 X0.75 | 10,5 | 46 | 183 |
| 1121233 | 3 G0.75 | 10,9 | 56 | 210 |
| 1121235 | 4 G0.75 | 11,4 | 67 | 238 |
| 1121236 | 4 X0.75 | 11,4 | 67 | 238 |
| 1121237 | 5 G0.75 | 12,1 | 78 | 272 |
| 1121241 | 7 G0.75 | 12,9 | 97 | 315 |
| 1121247 | 12 G0.75 | 15,8 | 168 | 464 |
| 1121251 | 18 G0.75 | 18 | 229 | 616 |
| 1121254 | 25 G0.75 | 20,7 | 296 | 762 |
| 1121266 | 2 X1.0 | 10,8 | 52 | 198 |
| 1121267 | 3 G1.0 | 11,2 | 66 | 228 |
| 1121268 | 3 X1.0 | 11,2 | 66 | 228 |
| 1121269 | 4 G1.0 | 11,8 | 79 | 261 |
| 1121270 | 4 X1.0 | 11,8 | 79 | 261 |
| 1121271 | 5 G1.0 | 12,6 | 93 | 300 |
| 1121274 | 7 G1.0 | 13,3 | 117 | 335 |
| 1121280 | 12 G1.0 | 16,4 | 204 | 522 |
| 1121284 | 18 G1.0 | 18,7 | 280 | 687 |
| 1121290 | 25 G1.0 | 21,6 | 369 | 884 |
| 1121306 | 2 X1.5 | 11,8 | 69 | 243 |
| 1121307 | 3 G1.5 | 12,3 | 87 | 273 |
| 1121308 | 3 X1.5 | 12,3 | 87 | 273 |
| 1121309 | 4 G1.5 | 13 | 102 | 290 |
| 1121310 | 4 X1.5 | 13 | 102 | 290 |
| 1121311 | 5 G1.5 | 13,9 | 125 | 352 |
| 1121314 | 7 G1.5 | 15 | 180 | 448 |
| 1121320 | 12 G1.5 | 18,7 | 281 | 690 |
| 1121324 | 18 G1.5 | 21,8 | 391 | 938 |
| 1121328 | 25 G1.5 | 25,1 | 518 | 1180 |
| 1121340 | 3 G2.5 | 13,5 | 123 | 354 |
| 1121342 | 4 G2.5 | 14,6 | 168 | 413 |
| 1121344 | 5 G2.5 | 15,7 | 204 | 515 |
| 1121346 | 7 G2.5 | 17 | 265 | 619 |
| 1121349 | 12 G2.5 | 21,7 | 421 | 936 |
| 1121360 | 4 G4 | 16,2 | 238 | 587 |
| 1121361 | 5 G4 | 17,7 | 302 | 689 |
| 1121362 | 7 G4 | 19 | 396 | 828 |
| 1121367 | 4 G6 | 17,7 | 318 | 715 |
| 1121368 | 5 G6 | 19,2 | 419 | 862 |
| 1121369 | 7 G6 | 21,2 | 559 | 1105 |
| 1121372 | 4 G10 | 21,7 | 574 | 875 |
| 1121373 | 5 G10 | 23 | 612 | 1037 |
| 1121377 | 4 G16 | 24,3 | 809 | 1198 |
| 1121378 | 5 G16 | 26,7 | 935 | 1500 |
| 1121381 | 4 G25 | 29,8 | 1,165.0 | 1814 |
| 1121382 | 5 G25 | 31,6 | 1,400.0 | 2164 |
| 1121385 | 4 G35 | 32,7 | 1,683.0 | 2893 |
| 1121388 | 4 G50 | 39,6 | 2,368.0 | 4094 |
| 1121391 | 4 G70 | 44,5 | 3,261.0 | 5467 |
| 1121394 | 4 G95 | 51 | 4,055.0 | 5849 |
| 1121397 | 4 G120 | 58,1 | 5,225.0 | 7509 |
