Cat 5E 2-pair 24AWG F/UTP Shielded Cable
DESCRIPTION
Rating Temp : 75°C
Flame Test : CM
Application : Horizontal Wiring
Standard : ISO 11801, TIA/EIA 568B.2, UL444
CONSTRUCTION & DIMENSION
Conductor :
Material : Solid Plain Copper
AWG : 24 AWG
Conductor Dia: 0.576 ± 0.005 mm
Insulation :
Material : HD PE
Min. Ave. Thickness : 0.28 mm
Min. Thickness at any point : 0.217mm
Diameter : 1.030 ± 0.05 mm
Identification :
1. Blue x White / Blue
2. Orange x White / Orange
Inner Sheath : PVC
Drain Wire : Tinned Copper
Shield : Aluminium Foil
Jacket :
Material : PVC
Min. Ave. Thickness : 0.55 mm
Diameter : 7.8 ± 0.3 mm
ELECTRICAL & PHYSICAL PROPERTIES
| FREQ. | ATTN. | NEXT | ACR | RL | PS NEXT | PS ACR | ELFEXT | PS ELFEXT |
| MHz | dB/100m | dB | dB/100m | dB | dB | dB/100m | dB | dB |
| 1 | 2 | 67 | 65 | 20 | 65 | 63 | 69 | 66 |
| 4 | 4 | 58 | 54 | 23 | 56 | 52 | 56.8 | 53.8 |
| 10 | 6.3 | 52 | 45.7 | 25 | 50 | 43.7 | 49 | 46 |
| 16 | 8 | 48.9 | 40.9 | 25 | 46.9 | 38.9 | 44.8 | 41.8 |
| 20 | 9 | 47.5 | 38.5 | 25 | 45.5 | 36.5 | 42.5 | 39.5 |
| 31.25 | 11.4 | 44.6 | 33.2 | 23.6 | 42.6 | 31.6 | 39 | 36 |
| 62.5 | 16.5 | 40.1 | 23.6 | 21.5 | 38.1 | 21.6 | 32.9 | 29.9 |
| 100 | 21.3 | 37 | 15.7 | 20.1 | 35 | 13.7 | 29 | 26 |
| 200 | 32.42 | 30.78 | – | 18.92 | 27.78 | – | 17.87 | 14.78 |
| Part No. | Description |
| 301-10F02E-03GY | Cat 5E 2-pair 24AWG F/UTP Shielded Cable, PVC, 305m/reel |
