Bảo vệ cách ly 3Onedata ( Model232I(RS-232 Isolation Protector) ) RS-232 Isolator Protector, 2500V isolation | Chính Hãng – Giá Tốt Nhất
Model : Model232I
Model232I is a kind of RS232 system communication serial port optic isolation product. This product support transmission rate as high as 912600bps, no external power needed, optic electric isolation 2500V, is applicable in tough environment. According to different customer need, separately corresponds to three line serial port application with RTS/CTS (or DTR/CTS). Transmission distance at 9,600bps is 10m, stable performance.
Features
1. Plug-and-play
2. Port-powered, lowest consumption
3. Auto sense serial signal rate
4. Isolation serial device(RS-232)
5. 2500V isolation
6. 300~912600bps baud rates
2. Port-powered, lowest consumption
3. Auto sense serial signal rate
4. Isolation serial device(RS-232)
5. 2500V isolation
6. 300~912600bps baud rates
Specification
Performance parameter
Standard: EIA RS-232 standard
RS-232 signal: TXD,RXD, GND
Working: Asynchronous, point to point
Transfer rate: 300-912600bps,auto sense serial signal rate
Isolate signal: TXD,RXD, GND
Transfer distance: 5m
RS-232 port protection: 600W surge,15KV ESD protection
Isolation: 2500V
Port type: DB9F, DB9M
Environment
Working environment: 0°C to 70°C
Storage temperature: -40°C to 85°C
Relative humidity 5% to 95%
Appearance guideline
L×W×H: 90mm×33mm×16.5mm (DB9)
Shell: Plastic
Color: Black
Weight:30g (DB9)
Warranty: 3 years
Approvals: FCC,CE, RoHS approvals
