Bộ chuyển đổi UPCOM ( MC102-S-80 ) 2-port 10/100M Ethernet, Single-mode, 80Km, 5VDC, SC, FC or ST, optional | Chính Hãng – Giá Tốt Nhất – Giá Rẻ Nhất
- 2-port 10/100M Ethernet Media ConverterMC102MC102 complies with IEEE802.3, IEEE802.3u, IEEE802.3x Standards. It is designed to convert data signal between 10/100 Base-TX and 100Base-FX fast Ethernet. It supports 10/100Base-TX and 100Base-FX applications. The data signal converted by such high performance media converter can be transmitted up to 120Km maximum by fiber-optical cable. The Converter is equipped one optic port and two RJ45 Jacks and one external power supply receptacle.
Introduction
MC102 complies with IEEE802.3, IEEE802.3u, IEEE802.3x Standards. It is designed to convert data signal between 10/100 Base-TX and 100Base-FX fast Ethernet. It supports 10/100Base-TX and 100Base-FX applications. The data signal converted by such high performance media converter can be transmitted up to 120Km maximum by fiber-optical cable. The Converter is equipped one optic port and two RJ45 Jacks and one external power supply receptacle. LED indicators are built-in for easy diagnosing and monitoring the status of. It can be configured automatically for Full Duplex or Half Duplex operation.
Features
1. Accord to IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3 100Base-FX
2. MDI/MDI-X auto negotiation, 10M/100M auto negotiation
3. Supports full /half duplex, Point-to-point transparent transfer
4. Power External 5VDC input
5. Plug-and-play, easy to installation
6. High-performance 155Mbps bandwidth.
7. Complies with FCC, 15 CLASS A ,RoHs and CE MARK
8. Can insert to 2U 19″, 14 slots Rackmount(power external)
| Interface | |
| Standards | comply with IEEE802.1 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3 100Base-FX |
| RJ45 port rate | 10/100Mbps auto negotiation |
| Optic port rate | 100Mbps |
| Working | Asynchronous, point to point |
| Transfer distance | |
| RJ45port | 100m |
| Fiber optic | 20,40,60,80,100,120km(SM), 2 km(MM) optional |
| RJ45 port cable | UTP 5E |
| Fiber connector | SC,ST,FC optional |
| Fiber optic cables | Single Mode:8.3/125,8.7/125,9/125 or 10/125 um, Muti-Mode:50/125,62.5/125 um |
| Wavelength | 850nm,1310nm,1550nm |
| Power | |
| Power supply | External 5VDC input |
| Consumption | 4W |
| Environment | |
| Operating temperature | -25°C to50°C |
| Storage temperature | -35°C to 70°C |
| Operating humidity | 5% to 95%(no condensation) |
| Dimensions: | 110×70×25mm(Power External) |
| Shell | Iron |
| Color | Black |
| Weight | 180g(power external) |
| Warranty | 3 years |
| Approvals | FCC,CE, RoHS approvals |
| Model NO. | Description |
| MC102-M-2 | multi-mode, 2Km, 5VDC, SC, FC or ST, optional |
| MC102-S-20 | single-mode, 20Km,5VDC, SC, FC or ST, optional |
| MC102-S-40 | single-mode, 40Km, 5VDC, SC, FC or ST, optional |
| MC102-S-60 | single-mode, 60Km, 5VDC, SC, FC or ST, optional |
| MC102-S-80 | single-mode, 80Km, 5VDC, SC, FC or ST, optional |
| MC102-S-100 | single-mode, 100Km,5VDC, SC, FC or ST, optional |
| MC102-S-120 | single-mode, 120Km, 5VDC, SC, FC or ST, optional |
| MC102-SS-20 | single-mode, single fiber, 20Km, 5VDC, SC, FC or ST, optional |
| MC102-SS-40 | single-mode, single fiber, 40Km, 5VDC, SC, FC or ST, optional |
| MC102-SS-60 | single-mode, single fiber, 60Km, 5VDC, SC, FC or ST, optional |
| MC102-SS-80 | single-mode, single fiber, 80Km, 5VDC, SC, FC or ST, optional |
