LiFY
Flexible at cold temperatures, class 6 single core for devices or measurements
LIFY, power and control cable, PVC special single core, extra-finely stranded/extremely flexible measuring cable, protected for low voltage, flame-retardant, max. +70°C
Extremely flexible / extra-fine wire
Benefits
- Very soft PVC insulation that is flexible at low temperatures
Application range
- For use in and on mobile equipment
- For measuring assemblies in technical training sessions, education and electric laboratories
Norm references / approvals
- Based on VDE 0812 and VDE 0250-1
Design
- Copper stranded wire
- PVC-based core insulation
Classification
- ETIM 5.0 Class-ID: EC000993
- ETIM 5.0 Class-Description: Single-core cable
Conductor design
- Extra-finely stranded IEC braided conductor class 6: 0.07 mm
Nominal voltage
- Highly flexible LiFY cores:
up to 1.0 mm²: U0/U: 300/500 V,
from 1.5 mm²: U0/U: 450/750 V
Temperature range
- Flexible use: -15°C to +70°C
| Article number | Conductor cross-section (mm²) | Outer diameter [mm] | Core colour | Copper index (kg/km) |
| 4560017S | 0.75 | 2.5 | green/yellow | 7.2 |
| 4560013S | 0.75 | 2.5 | black | 7.2 |
| 4560014S | 0.75 | 2.5 | blue | 7.2 |
| 4560016S | 0.75 | 2.5 | red | 7.2 |
| 4560027S | 1 | 2.9 | green/yellow | 9.6 |
| 4560023S | 1 | 2.9 | black | 9.6 |
| 4560024S | 1 | 2.9 | blue | 9.6 |
| 4560026S | 1 | 2.9 | red | 9.6 |
| 4560037S | 1.5 | 3.7 | green/yellow | 14.4 |
| 4560033S | 1.5 | 3.7 | black | 14.4 |
| 4560034S | 1.5 | 3.7 | blue | 14.4 |
| 4560036S | 1.5 | 3.7 | red | 14.4 |
| 4560057S | 2.5 | 4.2 | green/yellow | 24 |
| 4560053S | 2.5 | 4.2 | black | 24 |
| 4560054S | 2.5 | 4.2 | blue | 24 |
| 4560056S | 2.5 | 4.2 | red | 24 |
| 4560063 | 4 | 5.1 | black | 38.4 |
| 4560067 | 4 | 5.1 | green/yellow | 38.4 |
| 4560064 | 4 | 5.1 | blue | 38.4 |
| 4560077 | 6 | 6 | green/yellow | 57.6 |
| 4560073 | 6 | 6 | black | 57.6 |
| 4560074 | 6 | 6 | blue | 57.6 |
| 4560076 | 6 | 6 | red | 57.6 |
| 4560087 | 10 | 7.4 | green/yellow | 96 |
| 4560083 | 10 | 7.4 | black | 96 |
| 4560086 | 10 | 6.6 | red | 96 |
■ Accessories
▯ DIN-assorted boxes conductor end sleeves
▯ PEW 8.87 crimping pliers
▯ KS 15 cable shears
