LiFY 1 kV
Flexible at cold temperatures, class 6 single core for devices or measurements
LIFY 1 kV, power and control cable, PVC special single core, extra-finely stranded measuring cable, reinforced insulation/protected up to 1 kV, flame-retardant max. +70°C
Extremely flexible / extra-fine wire
Benefits
- Very soft PVC insulation that is flexible at low temperatures
Application range
- For use in and on mobile equipment
- The 1000 V version with thicker insulation wall is suitable for many measuring instruments such as multimeters
- For measuring assemblies in technical training sessions, education and electric laboratories
Norm references / approvals
- Based on VDE 0812 and VDE 0250-1
Design
- Copper stranded wire
- PVC-based core insulation
Classification
- ETIM 5.0 Class-ID: EC000993
- ETIM 5.0 Class-Description: Single-core cable
Conductor design
- Extra-finely stranded IEC braided conductor class 6: 0.07 mm
Nominal voltage
- LiFY test cores:
U: 1000 VAC
Temperature range
- Flexible use: -15°C to +70°C
| Article number | Conductor cross-section (mm²) | Outer diameter [mm] | Core colour | Copper index (kg/km) |
| 4560011S | 0.75 | 4 | black | 7.2 |
| 4560021S | 0.75 | 4 | blue | 7.2 |
| 4560041S | 0.75 | 4 | red | 7.2 |
| 4560012S | 1.5 | 4 | black | 14.4 |
| 4560022S | 1.5 | 4 | blue | 14.4 |
| 4560042S | 1.5 | 4 | red | 14.4 |
■ Accessories
▯ DIN-assorted boxes conductor end sleeves
▯ PEW 8.87 crimping pliers
▯ KS 15 cable shears
