ESUY copper earthing cable
Flexible single core for grounding and shorting as well as for grounding installations and potential equalisation
ESUY special single core, stranded earthing cable for grounding and shorting or as potential equalisation, highly flexible, transparent PVC sheath, flame-retardant
- Grounding, shorting prior to maintenance
- Mechanically highly flexible
Benefits
- Very flexible despite a large conductor cross-section
Application range
- Provides protection during repairs
- For earthing in high-voltage power installations of power companies and in traction current installations for railways
- For earthing devices and potential equalisation on machine parts and EDP systems
Product features
- Flame-retardant according to IEC 60332-1-2
Design
- Conductor made of bare copper wires
- Braiding made of bare copper wires
- Outer sheath: Based on PVC, transparent
Classification
- ETIM 5.0 Class-ID: EC000993
- ETIM 5.0 Class-Description: Single-core cable
Conductor design
- refer to article table
Minimum bending radius
- Flexible use: 12 x outer diameter
Test voltage
- 2000 V
Temperature range
- Flexible use: -5°C to +70°C
| Article number | Conductor cross-section (mm²) | Conductor stranding: number of wires x wire diameter (mm) |
Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 4571101 | 16 | 4200 x 0.07 | 8.8 | 177 | 230 |
| 4571102 | 25 | 3192 x 0.1 | 10.4 | 275 | 316 |
| 4571103 | 35 | 4480 x 0.1 | 12.4 | 387 | 475 |
| 4571104 | 50 | 6383 x 0.1 | 14.6 | 560 | 670 |
| 4571105 | 70 | 8918 x 0.1 | 17 | 791 | 905 |
| 4571106 | 95 | 12100 x 0.1 | 19.8 | 1,069.00 | 1220 |
