ÖLFLEX® TRUCK 170 FLRYY
ÖLFLEX® TRUCK 170 FLRYY, ADR/TÜV/DIN ISO 4141-3 & 6722, power and control cable for trucks/commercial vehicles, PVC, 60 V DC, -40°C to +85°C, UV-/oil-resistant
- tested according to ECE-R 118.01
- Hazardous materials transportation
Benefits
- Special ADR approval
- ADR approval enables use in all trailers and semi-trailers transporting hazardous goods
Application range
- tested according to ECE-R 118.01
- Wiring electrical installations for all trailers and semi-trailers
Product features
- UV-resistant
- Resistant to cold temperatures
- Resistant to most oils, chemicals and weather conditions
Norm references / approvals
- ISO 4141 and DIN/ISO 6722
Design
- Conductor made of bare copper wires
- PVC-based core insulation
- Special PVC-based outer sheath
| Article number | Number of cores and mm² per conductor |
Outer diameter (mm) |
Colour | Copper index (kg/km) |
Weight (kg/km) |
| ÖLFLEX® TRUCK 170 FLRYY | |||||
| 7027060 | 2 x 1,0 | 6 | white-black | 19.2 | 55 |
| 7027061 | 2 x 1,0 | 6 | white-brown | 19.2 | 55 |
| 7027000 | 2 x 1,5 | 6.6 | white-black | 28.8 | 68 |
| 7027001 | 2 x 1,5 | 6.6 | white-brown | 28.8 | 68 |
| 7027062 | 3 x 1,0 | 6.3 | black-brown-blue | 28.80 | 63 |
| 7027012 | 3 x 1,0 | 6.3 | white/brown/blue, newest ISO design | 28.8 | 63 |
| 7027063 | 4 x 1,0 | 6.8 | white/black/red/brown | 38.4 | 81 |
| 7027034 | 4 x 1,5 | 7.5 | white/black/red/brown | 57.6 | 106 |
| 7027064 | 5 x 1,0 | 7.5 | white/brown/green/red/grey | 48 | 97 |
| 7027065 | 5 x 1,0 + 1 x 2,5 | 9 | 1.0 = green/brown/red/blue/violet; 2.5 = white | 72 | 133 |
| 7027066 | 5 x 1,0 + 1 x 2,5 | 9 | 1.0 = yellow/black/red/blue/violet; 2.5 = white | 72 | 133 |
| 7027015 | 5 x 1,0 + 1 x 2,5 | 9 | 1.0 = brown/green/red/grey/violet; 2.5 = white, newest ISO design | 72 | 133 |
| 7027016 | 5 x 1,0 + 1 x 2,5 | 9 | 1.0 = brown/yellow/red/grey/violet; 2.5 = white, newest ISO design | 72 | 133 |
| 7027007 | 7 x 0,75 | 7.3 | white/black/yellow/red/green/brown/blue | 50.4 | 101 |
| 7027067 | 7 x 1,5 | 8.9 | white/black/yellow/red/green/brown/blue | 100.8 | 166 |
| 7027068 | 6 x 1,5 + 1 x 2,5 | 10.3 | ISO 4141 1.5 = black/yellow/red/green/brown/blue; 2.5 = white | 110.4 | 187 |
| 7027069 | 8 x 1,5 + 1 x 2,5 | 11.7 | ISO 4141 + grey/violet | 139.2 | 239 |
| 7027070 | 10 x 1,5 + 3 x 2,5 + 1x(2×1,5) | 14.4 | white with black numbers; 1.5 = no. 1 – 3, 5 – 8, 10 – 12; 2.5 = no. 4, 9, 13; 1.5 = no. 14, 15 |
244.8 | 391 |
| 7027010 | 10 x 1,5 + 3 x 2,5 + 1x(2×1,5) | 14.4 | ISO 12098 | 244.8 | 391 |
| 7027071 | 10 x 1,5 + 3 x 2,5 | 14.4 | white with black numbers; 1.5 = no. 1 – 3, 5 – 8, 10 – 12; 2.5 = no. 4, 9, 13 | 216 | 367 |
| 7027035 | 2 x 0,75 + 2 x 1,5 | 7.2 | 0.75 = white-brown; 1.5 = yellow-green | 43.2 | 85 |
| 7027017 | 5 x 1,5 + 2 x 2,5 | 10.3 | 1.5 = black/yellow/green/brown/blue; 2.5 = white/red | 120 | 217 |
| 7027004 | 8 x 1,5 + 5 x 2,5 | 14.8 | 1.5 = yellow/blue/green/brown/red/black/pink/white-blue; 2.5 = white/orange/grey/white-black/white-red |
235.2 | 360 |
| 7027073 | 9 x 1,5 + 4 x 2,5 | 14.8 | white with black numbers; 1.5 = no. 2, 4 – 8, 10 – 12; 2.5 = no. 1, 3, 9, 13 | 225.6 | 352 |
| 7027074 | 4 x 6 + 1 x 1,5 | 13.7 | 1.5 = grey; 6.0 = brown/red/black/blue | 244.8 | 352 |
