ÖLFLEX® TRUCK 170 TWIN
ÖLFLEX® TRUCK 170 TWIN, ADR/TÜV/ISO 6722, power and control cable, flat TWIN battery cable made of PVC for trucks/commercial vehicles, 60 V, -40°C/+85°C
- tested according to ECE-R 118.01
- Hazardous materials transportation
- Battery twin cable
Benefits
- Polarity identification is possible without stripping or external marking (the item designation is always printed on the positive pole). This rules out incorrect connections
- No brushing of the strands after stripping and therefore optimum subsequent handling, for example when crimping/contacting
- Special ADR approval
Application range
- Battery cable between the power source and the end user
- tested according to ECE-R 118.01
Product features
- Double-sheathed, very robust and therefore for installation without corrugated pipe
- Very strong bar connection but offering easy separation of the cable by hand
Norm references / approvals
- ADR certification TÜ.EGG.091-04
Design
- Conductor made of bare copper wires
- PVC-based core insulation
- Special PVC-based outer sheath
Classification
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Minimum bending radius
- 15 x outer diameter
Nominal voltage
- 60 V DC
Test voltage
- 3000 V AC
Temperature range
- Fixed installation: -40°C to +85°C
- Area of application, class A
| Article number | Number of cores and mm² per conductor | Outer dimensions, width x height (mm) | Copper index (kg/km) |
| ÖLFLEX® TRUCK 170 TWIN PVC/PVC | |||
| 7027055 | PVC/PVC 2 x 6,0 | 15.2 x 7.1 | 115.2 |
| 7027056 | PVC/PVC 2 x 10,0 | 18.8 x 8.9 | 192 |
| 7027057 | PVC/PVC 2 x 16,0 | 21.0 x 10.0 | 307.2 |
| 7027058 | PVC/PVC 2 x 25,0 | 25.6 x 12.3 | 480 |
| 7027059 | PVC/PVC 2 x 35,0 | 28.4 x 13.5 | 672 |
| 7027054 | PVC/PVC 2 x 50,0 | 33.0 x 16.0 | 960 |
| 7027052 | PVC/PVC 2 x 70,0 | 39.8 x 18.4 | 1,344.00 |
