Two-Conductor Shielded Cables (Single) Braided Shield

Model Number

L-2E5

Miniature version of L-2T2S when small size and light weight is a consideration. Useful for patch cables, hidden lavaliere microphones or any balanced audio installation.
● Microphones.
● Portable Applications.
● Audio Patch Cords.
● PA Systems.
● Braided Copper Shield.
● Flexible in Extreme Cold Weather.
● Reduced Handling Noise.
● Rejects EMI and RFI.

MECHANICAL SPECIFICATIONS

Model

Std.
Lng.

ft.
(m)

Wt
Std.
Lng.
lbs
(kgs)

Nom.
O.D.

in.
(mm)

Jacket
Nom.
Thick.
in.
(mm)

Brittle
Point

F°
(C°)

No.
of
Cond.

Insul.

Type*
Thick
mil

Cond-AWG
(Qty./mil)
Cross Sec.
Area
mil.²

Pitch
Twist
Quad
in.
(mm)

Shield
Cover-
age

L-2E5

656
(200)

20.2
(9)

.181
(4.6)

.035
(0.9)

-56
(-49)

IPE

AC – #26
(30/3.15)
322.5

<0.79
(-)

>96.7%
TAC
Braid

*Dielectric Strength = 500V AC/1min. Insulation Resistance/3Mft = >1000M ohm.
**Effective AWG of combined twin conductors.

ELECTRICAL PERFORMANCE

Model

Cond.
D.C.R.
ohm/1000ft
(ohm/100m)

Shield
D.C.R.
ohm/1000ft
(ohm/100m)

Nom.
Cap.
***

pF/m

Nom.
Cap.
†

pF/m

Nom.
Imp.
ohm

Nom.
Atten.
V/1000ft
(V/100m)

Group
Delay
Time
nS/ft
(nS/m)

L-2E5

<38.7
(<12.7)

<6.7
(<2.2)

–

***Capacitance between conductors.
†Capacitance between conductors to shield.

COLORS AVAILABLE
Model	Black	Blue	Brown	Gray	Green	Orange	Purple	Red	White	Yellow
L-2E5	[+]	– –	– –	– –	– –	– –	– –	– –	– –	– –

[+]=Standard Color, [o]=Available Color, “- -“=n/a
