Data Cable
Model Number
D403-AT
Star Quad style 64 ohm data control cable also usable for MIDI harness wiring. Four #22 Gauge Individually Color Coded Conductors. 100% Aluminum Foil shield with integral drain wire. Excellent pulling strength. Jacket color: SEPIA.
● TX, RX Data.
● MIDI Harness.
● Individual Color Unit.
● 100% Aluminum Foil Sheild with Drain Wire.
● Rejects EMI.
| Model | Std. Lng.
ft. |
Wt. Std. Lng. lbs. |
Nom. O.D. in. |
Cond. Strand Qty./mm |
Insul. Type* Color |
Jacket Thick. in. |
Nom. Imp. ohm |
Shield Coverage |
| D403-AT | 656 (200) |
36 (16) |
.205 (5.2) |
7/0.26 (TAC 0.37) #22 |
IPE RED,GRN, WHT,YEL |
PVC .040 (1.0) |
64 | AL Foil 100% |
*Dielectric Strength = 500V AC/1min. Insulation Resistance/3Mft = >1000M ohm.
| Model | Black | Blue | Brown | Gray | Green | Orange | Purple | Red | Sepia | White | |
| D403-AT | – – | – – | – – | – – | – – | – – | – – | – – | [+] | – – | |
[+]=Standard Color, [o]=Available Color, “- -“=n/a
