Star Quad Microphone Cable
Model Number
L-4E5C
Features
L-4E5C
A narrow profile version of L-4E6S. Specifically designed to save space and reduce weight during remote field expeditions or confining installations.
A narrow profile version of L-4E6S. Specifically designed to save space and reduce weight during remote field expeditions or confining installations.
L-4E5C
A narrow profile version of L-4E6S. Specifically designed to save space and reduce weight during remote field expeditions or confining installations.
A narrow profile version of L-4E6S. Specifically designed to save space and reduce weight during remote field expeditions or confining installations.
● Microphones.
● Portable Applications.
● Audio Rack Wiring.
● PA Systems.
● Audio Patch Cords.
● Braided Copper Shield.
● Flexible in Extreme Cold Weather.
● Cross Linked PE Insulation.
● Reduced Handling Noise.
● Rejects EMI and RFI.
● 10 Matte Color Jacket Selections.
The Star Quad Story (Catalog PDF)
| Model | Std. Lng. ft. (m) |
Wt Std. Lng. lbs (kgs) |
Nom. O.D. in. |
Jacket Nom. Thick. in. |
Brittle Point F° |
No. of Cond. |
Insul.
Type* |
Cond-AWG (Qty./mil) Cross Sec. Area mil.² **Quad AWG |
Pitch Twist Quad in. |
Shield Cover- age |
| L-4E5C | 656 (200) |
18 (8) |
.189 (4.80) |
PVC .032 (0.80) |
-56 (-49) |
4 2 Blue 2Wht |
IPE 11.8 |
AC – #26 30/3.15 232.5 #23 |
.71 (18) |
>96% TAC Braid |
*Dielectric Strength = 500V AC/1min. Insulation Resistance/3Mft = >1000M ohm.
**Effective AWG of combined twin conductors.
**Effective AWG of combined twin conductors.
| Model | Cond. D.C.R. ohm/1000ft |
Shield D.C.R. ohm/1000ft |
Nom. Cap. *** pF/m |
Nom. Cap. † pF/m |
Nom. Imp. (ohm) |
Nom. Atten. V/1000ft |
Group Delay Time nS/ft (nS/m) |
| L-4E5C | <39.7 (<13.0) |
<7.6 (<2.5) |
162 | 200 | 40 | 0.9 (0.3) |
1.71 (5.6) |
***Capacitance between twin Blue and twin White conductors.
†Capacitance between conductors to shield.
†Capacitance between conductors to shield.
| Model | Black | Blue | Brown | Gray | Green | Orange | Purple | Red | White | Yellow | |
| L-4E5C | [+] | [o] | – – | [o] | [o] | [o] | – – | [o] | – – | [o] | |
[+]=Standard Color, [o]=Available Color, “- -“=n/a
