Cáp CANARE ( L-4E3-8P ) 8 x 4 x 28AWG | Chính Hãng – Chống Nhiễu từng Pair – Giá Tốt Nhất – Giá Rẻ Nhất

Cáp CANARE ( L-4E3-8P ) 8 x 4 x 28AWG | Chính Hãng – Chống Nhiễu từng Pair – Giá Tốt Nhất – Giá Rẻ Nhất

Multichannel Star Quad Microphone Cable
Model Number
L-4E3-P Series
A 25 AWG multichannel Star Quad snake cable with raided shields. Each channel is completely isolated and consists of 4 conductors surrounded by an overall braided shield encased in a color coded striped PVC jacket. Fine conductor stranding for flexibility, facilitates roll up and easy payout. The four conductor design provides superior EMI and RFI noise rejection in problem areas on stage.
Excellent crosstalk characteristics allow vastly different signals (-120dB mic, +4dB line, +10dB code levels) to be used in adjacent channels.Note: All Canare DT12 Snake assemblies are built using our road-worthy
and flexible L-4E3-12P cable.

●  Multiple Audio Lines.
●  Portable Applications.
●  Audio Rack Wiring.
●  PA Systems.
●  Braided Copper Shield.
●  Flexible in Extreme Cold Weather.
●  Cross Linked PE Insulation.
●  Rejects EMI and RFI.
●  Multiple Channels.

MECHANICAL SPECIFICATIONS
Model Std. Lng.

ft.
(m)

No. of
Channels
(Pairs)
No. of
Cond.
(4 Per
Channel)
Wt
Std. Lng.lbs
(kgs)
Nom.
O.D.in.
(mm)
PVC
Jacket
Nom.
Thick.
in.
(mm)
Brittle
PointF°
(C°)
L-4E3-2P 328
(100)656
(200)
2 8 18
(8)
.350
(8.8)
.032
(0.8)
-22
(-30)
L-4E3-4P 4 16 31
(14)
.429
(10.9)
.043
(1.1)
L-4E3-8P 8 32 57
(26)
.602
(15.3)
.051
(1.3)
L-4E3-12P 12 48 79
(36)
.685
(17.4)
.051
(1.3)
L-4E3-16P 16 64 101
(46)
.744
(18.9)

.047
(1.2)

L-4E3-24P 24 96 154
(70)
.945
(24.0)
.059
(1.5)
(contd.) MECHANICAL SPECIFICATIONS
Model Channel
O.D.in.
(mm)
Channel
Jacket
Nom.
Thick.mil
Insul.
Type*
Thickmil
Cond-AWG
(Qty./mil)
Cross Sec. Area
mil.²
**Quad AWG
Pitch
Twist
Quad
in.
(mm)
Shield
Coverage
Channel
Drain Wire
(Bundle
Drain Wire)
L-4E3-P
Series
.134
(3.4)
PVC
11.8
IPE
10.6
AC – #28
(7/4.72)
124
#25
<0.63
(<16)
AC Braid
>93%
_
(20AWG)
*Dielectric Strength = 500V AC/1min. Insulation Resistance/3Mft = >1000M ohm.
**Effective AWG of combined twin conductors.
ELECTRICAL PERFORMANCE
Model Cond.
D.C.R.ohm/
1000ft
(ohm/
100m)
Shield
D.C.R.ohm/
1000ft
(ohm/
100m)
Nom.
Cap.
***pF/m
Nom.
Cap.
†pF/m
Nom.
Imp.ohm
Nom.
Atten.V/1000ft
(V/100m)
Group
Delay
TimenS/ft
(nS/m)
X-Talk
Input
3.31VmV/
1000ft
(mV/
100m)
L-4E3-P
Series
<75.8
(<24.9)
<10.3
(<3.4)
145 170 43 1.8
(0.6)
1.8
(5.8)
<3
(<1)
***Capacitance between conductors.
†Capacitance between conductors to shield.

COLORS AVAILABLE
Model Black Blue Brown Gray Green Orange Purple Red White Yellow
L-4E3-P
Series
[+] – – – – – – – – – – – – – – – – – –
[+]=Standard Color, [o]=Available Color, “- -“=n/a



Cross Section
Individual Star Quad Channel


L-4E3-P, L-4E4-AT Cross Section Multichannel Bundle

Channel Color Code
Ch. No. 1 2 3 4 5 6 7 8 9 10 11 12
Spiral
Markers
RED BLU YEL GRN BRN   – BLK
BLU
BLK
YEL
BLK
GRN
BLK
BRN
BLK ORN
BLU
(contd.) Channel Color Code
Ch. No. 13 14 15 16 17 18 19 20 21 22 23 24
Spiral
Markers
ORN
YEL
ORN
GRN
ORN
BRN
ORN PNK
BLU
PNK
YEL
PNK
GRN
PNK
BRN
PNK WHT
BLU
WHT
YEL
WHT
GRN
