ÖLFLEX® TRAIN 350 300V
Multi-core cable according to EN 50264-3-2 type MM for high requirements in railway applications
ÖLFLEX® TRAIN 350 300V – control cable EN 50264-3-2 type MM, for rail vehicles/trains, 300/500V, EN 45545: HL1-HL3, NF F 16-101: C/F0
- Meets EN 50264-3-2 type MM and
EN 45545-2 - High temperature resistance: -45°C to 90°C
- Highly oil- and fuel-resistant
Benefits
- Good chemical resistance
- Resistant to mechanical influences in harsh environmental conditions
- Extended temperature range
- Reduced flame spreading for protection against damage to persons and property in the event of a fire
Application range
- For use in railway vehicles and buses, for fixed installation and applications where limited movement is to be expected
- Suitable for connecting lamps, heating equipment, switchgear, terminal boxes and power supply
- Can also be used in oily environments and areas with increased ambient temperature
Product features
- Fire behaviour in accordance with EN/IEC:
– Halogen-free according to EN 60754-1
– No corrosive gases according to EN 60754-2
– No fluorine according to EN 60684-2
– No toxic gases according to EN 50305
– Low smoke density according to EN 61034-2
– Flame-retardant according to EN 60332-1-2
– No flame propagation according to EN 60332-3-24 / EN 60332-3-25 / EN 50305 - Fire behaviour in accordance with NF:
– Toxicity of combustion gases according to NF X 70-100
– Low smoke density according to NF X 10-702
– No flame propagation according to NF C 32-070, cat. C1 and C2 - Chemical properties:
– Oil-resistant according to EN 50264-3-2
– Fuel-resistant according to EN 50264-3-2
– Acid-resistant according to EN 50264-3-2
– Alkali-resistant according to EN 50264-3-2
– Ozone-resistant according to EN 50264-3-2/
EN 50305)
Norm references / approvals
- EN 50264-3-2 type MM
- EN 45545-2 HL1, HL2, HL3
- NF F 16-101 – classification: C / F0
(flame propagation / smoke)
Design
- Tin-plated copper strand, fine-wire
- Insulation: Electron beam cross-linked polymer compound EI 109
- Core colour: Black with white numbers
- Sheath: Electron beam cross-linked polymer-compound EM 104
- Sheath colour: Black
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- Black with white numbers
Conductor design
- Fine-wired according to IEC 60228 / VDE 0295, braided conductor class 5
Minimum bending radius
- Fixed installation:
≤ 12 mm: 3 x OD
> 12 mm: 4 x OD - Occasional flexing:
≤ 12 mm: 4 x OD
> 12 mm ≤ 20 mm: 5 x OD
> 20 mm: 6 x OD
(OD = outer diameter)
Nominal voltage
- U0/U: 300/500 V
- Um AC 600 V
V0 DC 450 V
Test voltage
- 2,0 kV AC; 4,8 kV DC
Protective conductor
- G = with GN-YE protective conductor
X = without protective conductor
Temperature range
- Fixed installation: -45°C to +90°C
- Occasional flexing:
-35°C to +90°C
Short circuit: +200°C (5s)
| Article number | Number of cores and mm² per conductor |
Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| 15350000 | 2 X 1 | 5.4 | 19.2 | 54.4 |
| 15350001 | 4 X 1 | 6.2 | 38.4 | 81.4 |
| 15350002 | 7 X 1 | 7.7 | 67.2 | 128.1 |
| 15350003 | 9 X 1 | 9.6 | 86.4 | 179.4 |
| 15350004 | 12 X 1 | 10.1 | 115.2 | 203.8 |
| 15350005 | 19 X 1 | 12.1 | 182.4 | 309 |
| 15350006 | 24 X 1 | 14.4 | 230.4 | 396.4 |
| 15350007 | 32 X 1 | 15.9 | 307.2 | 520.1 |
| 15350008 | 37 X 1 | 16.7 | 355.2 | 580.1 |
| 15350009 | 40 X 1 | 17.8 | 384 | 643.9 |
| 15350010 | 4 X 1.5 | 7.6 | 57.6 | 116.2 |
| 15350011 | 7 X 1.5 | 9.2 | 100.8 | 184 |
| 15350012 | 9 X 1.5 | 11.7 | 129.6 | 272.6 |
| 15350013 | 12 X 1.5 | 12.4 | 172.8 | 301.8 |
| 15350014 | 19 X 1.5 | 15 | 273.6 | 472.9 |
| 15350015 | 24 X 1.5 | 17.3 | 345.6 | 576.5 |
| 15350016 | 32 X 1.5 | 19.6 | 460.8 | 777.6 |
| 15350017 | 37 X 1.5 | 20.6 | 532.8 | 879.4 |
| 15350018 | 4 X 2.5 | 8.6 | 96 | 168.5 |
| 15350019 | 7 X 2.5 | 10.6 | 168 | 269.8 |
| 15350020 | 9 X 2.5 | 13.7 | 216 | 401.7 |
| 15350021 | 12 X 2.5 | 14.5 | 288 | 460.2 |
| 15350022 | 19 X 2.5 | 17 | 456 | 679.6 |
| 15350023 | 24 X 2.5 | 20.1 | 576 | 879.2 |
