ÖLFLEX® TRAIN 355 C 300V
Shielded multi-core cable according to EN 50264-3-2 type MM S for high requirements in railway applications
ÖLFLEX® TRAIN 355 C 300V – control cable shielded according to EN 50264-3-2 type MM S, for rail vehicles/trains, 300/500V, EN 45545: HL1-HL3, NF F 16-101: C/F0
- Meets EN 50264-3-2 type MM S and
EN 45545-2 - High temperature resistance: -45°C to 90°C
- Highly oil- and fuel-resistant
Benefits
- Copper shielding complies with EMC requirements and protects against electromagnetic interference
- Good chemical resistance
- Resistant to mechanical influences in harsh environmental conditions
- Extended temperature range
- Reduced flame spreading for protection against damage to persons and property in the event of a fire
Application range
- For use in railway vehicles and buses, for fixed installation and applications where limited movement is to be expected
- Suitable for connecting lamps, heating equipment, switchgear, terminal boxes and power supply
- Can also be used in oily environments and areas with increased ambient temperature
Product features
- Fire behaviour in accordance with EN/IEC:
– Halogen-free according to EN 60754-1
– No corrosive gases according to EN 60754-2
– No fluorine according to EN 60684-2
– No toxic gases according to EN 50305
– Low smoke density according to EN 61034-2
– Flame-retardant according to EN 60332-1-2
– No flame propagation according to EN 60332-3-24 / EN 60332-3-25 / EN 50305 - Fire behaviour in accordance with NF:
– Toxicity of combustion gases according to NF X 70-100
– Low smoke density according to NF X 10-702
– No flame propagation according to NF C 32-070, cat. C1 and C2 - Chemical properties:
– Oil-resistant according to EN 50264-3-2
– Fuel-resistant according to EN 50264-3-2
– Acid-resistant according to EN 50264-3-2
– Alkali-resistant according to EN 50264-3-2
– Ozone-resistant according to EN 50264-3-2/
EN 50305)
Norm references / approvals
- EN 50264-3-2 type MM S
- EN 45545-2 HL1, HL2, HL3
- NF F 16-101 – classification: C / F0
(flame propagation / smoke)
Design
- Conductor: Finely stranded wire made of tin-plated copper
- Insulation: Electron beam cross-linked polymer compound EI 109
- Core colour: Black with white numbers
- Wrapping: Halogen-free plastic film
- Shield: Tin-plated copper braiding
- Sheath: Electron beam cross-linked polymer-compound EM 104
- Sheath colour: Black
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- Black with white numbers
Conductor design
- Fine-wired according to IEC 60228 / VDE 0295, braided conductor class 5
Minimum bending radius
- Fixed installation:
≤ 12 mm: 3 x OD
> 12 mm: 4 x OD - Occasional flexing:
≤ 12 mm: 4 x OD
> 12 mm ≤ 20 mm: 5 x OD
> 20 mm: 6 x OD
(OD = outer diameter)
Nominal voltage
- U0/U: 300/500 V
- Um AC 600 V
V0 DC 450 V
Test voltage
- Core/core: 2 kV AC; 4,8 kV DC
- Core/screen: 2 kV AC; 4,8 kV DC
Protective conductor
- G = with GN-YE protective conductor
X = without protective conductor
Temperature range
- Fixed installation: -45°C to +90°C
- Occasional flexing:
-35°C to +90°C
Short circuit: +200°C (5s)
| Article number | Number of cores and mm² per conductor |
Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| 15355000 | 2 X 1 | 6.2 | 39.27 | 71.4 |
| 15355001 | 4 X 1 | 7.2 | 64.06 | 108.5 |
| 15355002 | 7 X 1 | 8.5 | 97.15 | 152 |
| 15355003 | 9 X 1 | 10.8 | 137.41 | 234.1 |
| 15355004 | 12 X 1 | 11.3 | 170.09 | 257.7 |
| 15355005 | 19 X 1 | 13.7 | 261.77 | 395 |
| 15355006 | 24 X 1 | 15.6 | 324.51 | 482.2 |
| 15355007 | 32 X 1 | 17.1 | 411.92 | 605.9 |
| 15355008 | 37 X 1 | 17.9 | 471.56 | 685.9 |
| 15355009 | 40 X 1 | 19.4 | 510.27 | 777.3 |
| 15355010 | 4 X 1.5 | 8.4 | 86.8 | 145.1 |
| 15355011 | 7 X 1.5 | 10.2 | 150.51 | 224 |
| 15355012 | 9 X 1.5 | 13.1 | 191.37 | 336 |
| 15355013 | 12 X 1.5 | 13.8 | 240 | 371.1 |
| 15355014 | 19 X 1.5 | 16.2 | 369.09 | 547.8 |
| 15355015 | 24 X 1.5 | 18.9 | 463.04 | 697.9 |
| 15355016 | 32 X 1.5 | 20.8 | 591.57 | 891.5 |
| 15355017 | 37 X 1.5 | 21.8 | 664.73 | 993.6 |
| 15355018 | 4 X 2.5 | 9.6 | 153.75 | 219.6 |
| 15355019 | 7 X 2.5 | 11.6 | 224.75 | 311.4 |
| 15355020 | 9 X 2.5 | 14.9 | 309.28 | 478.1 |
| 15355021 | 12 X 2.5 | 15.7 | 382.12 | 529.9 |
| 15355022 | 19 X 2.5 | 18.6 | 573.02 | 794.6 |
| 15355023 | 24 X 2.5 | 21.3 | 718.82 | 999.1 |
