Benefits

• Good chemical resistance
• Resistant to mechanical influences in harsh environmental conditions
• Extended temperature range
• Reduced flame spreading for protection against damage to persons and property in the event of a fire

Application range

• For use in railway vehicles and buses, for fixed installation and applications where limited movement is to be expected
• Suitable for connecting lamps, heating equipment, switchgear, terminal boxes and power supply
• Can also be used in oily environments and areas with increased ambient temperature

Product features

• Fire behaviour in accordance with EN/IEC:
  – Halogen-free according to EN 60754-1
  – No corrosive gases according to EN 60754-2
  – No fluorine according to EN 60684-2
  – No toxic gases according to EN 50305
  – Low smoke density according to EN 61034-2
  – Flame-retardant according to EN 60332-1-2
  – No flame propagation according to EN 60332-3-24 / EN 60332-3-25 / EN 50305
• Fire behaviour in accordance with NF:
  – Toxicity of combustion gases according to NF X 70-100
  – Low smoke density according to NF X 10-702
  – No flame propagation according to NF C 32-070, cat. C1 and C2
• Chemical properties:
  – Oil-resistant according to EN 50264-3-1
  – Fuel-resistant according to EN 50264-3-1
  – Acid-resistant according to EN 50264-3-1
  – Alkali-resistant according to EN 50264-3-1
  – Ozone-resistant according to EN 50264-3-1/
  EN 50305)

Norm references / approvals

• EN 50264-3-1 type M
• EN 45545-2 HL1, HL2, HL3
• NF F 16-101 – classification: C / F1
  (flame propagation / smoke)

Design

• Tin-plated copper strand, fine-wire
• Insulation: Electron beam cross-linked polymer compound EI 109
• Colour: Black
